Relay SPDT 12V 6A 840R Gold 34.51.7.012.5010
Varenummer:
93-156
Varekode:
F3451-12G
Vægt:
10 g
Lagerstatus:
Ikke på lager
Gruppe:
E6313
FINDER Power PCB Relays
Series: 34.51
Contact: SPDT
Rated Current: 6A
Housing: 28,0x5,0x15,0mm
E6313
FINDER Power PCB Relays
Series: 34.51
Contact: SPDT
Rated Current: 6A
Housing: 28,0x5,0x15,0mm
| Features |
| • Ultra-slim (5mm) • High-density mounting due to low dimensions • Low power consumption • High dielectric strength, low coil consumption • Protective separation according to VDE0106, EN50178, EN60204 to Contact and Coil • DC drive • Protection class II to VDE0631 / EN60730 |
 |
| Technical Specifications |
| |
| Contact: | SPDT |
| Contact Material | |
| F3451-_: | AgNi |
| F3451-_G: | AgNi+Au (5µm) |
| Rated Current: | 6A |
| Max. Switching Current: | 10A |
| Max. Switching Voltage: | 400V AC |
| Max. Switching Power | |
| AC1/230V: | 1500VA |
| AC15/230V: | 300VA |
| Creepage/Clearance: | 8/8mm |
| Operate/Release Time: | 5/3ms |
| Testing Voltage | |
| Coil/Contact: | 4000V AC |
| Opening Contact: | 1000V AC |
| Lifetime | |
| Mechanical: | 10x106 Operations |
| Electrical: | 60x103 Operations |
| Operating Temperature: | -40...+85°C |
| |
| Coil Data |
| Part Nr. | UN | Umin. | Umax. | IN | PN | RN |
| [V DC] | [V] | [V] | [mA] | [mW] | [W] | |
| F3451-12 | 12 | 8,4 | 18 | 14,2 | 170 | 840 |
| F3451-24 | 24 | 16,8 | 36 | 7,1 | 170 | 3350 |
| F3451-48 | 48 | 33,6 | 72 | 3,9 | 170 | 12300 |
| F3451-60 | 60 | 42,0 | 90 | 3,0 | 170 | 19700 |
| F3451-12G | 12 | 8,4 | 18 | 14,2 | 170 | 840 |
| F3451-24G | 24 | 16,8 | 36 | 7,1 | 170 | 3350 |
| F3451-60G | 60 | 42,0 | 90 | 3,0 | 170 | 19700 |
| UN = Rated Voltage, Umin. = Minimum Operating Voltage, Umax. = Maximum Operating Voltage, IN = Rated Current, PN = Rated Power, RN = Coil Resistance; All Specifications Measured at 20°C | ||||||
| ||||||
| Note |
| • Assembly by direct soldering on PCB or • PCB socket F9311, see product group E6481, or • DIN rail sockets F9301_ and F9351_, see product group E6485, or • installation of coupling relays F3851-_, see product group E6661. |
|
| Norms |
| Installation of high voltage systems with electronic equipment EN50178, VDE0106 Electrical control units for domestic purposes and similar applications IEC730-1, EN60730-1, VDE0631 T1 Characteristics according to IEC255-1-00, EN60255-1-00, VDE0435 T201 |
|
| Approvals |
  |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 5 pieces |
|
| Manufacturer |
 |
| http://www.findernet.com |
|
