  5. SMD Crystal 4.194.304Hz HC49S4

SMD Crystal 4.194.304Hz HC49S4

Varenummer:
92-832
Varekode:
QSMD004,194
Vægt:
0 g
Lagerstatus:
Ikke på lager

kr 9,00 9.0 DKK kr 9,00 Inklusiv moms

kr 9,00 Inklusiv moms

Anmod os om en pris

v/10
Kr. 7,04
v/25
Kr. 4,22
v/100
Kr. 2,81

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/54267/image_1920?unique=0248f6c https://elektroniklavpris.odoo.com/web/image/product.template/54267/image_1920?unique=0248f6c
Technical Specifications
Temperature Range:
 -10...+60°C
Frequency Tolerance (25°C):
 ±30ppm
Shunt Capacitance, Max.:
 7pF
Quartz Load:
 1,0mW
Insulation Resistance (100V DC):
 >500MW
Temperature Stability:
 ±50ppm
Vibration Mode:
 Fundamental Wave
Aging:
 ±5ppm/Year
Technical Specifications
Part Nr.
 Frequency
 C
 RESR

  [Hz]
 [pF]
 [W]

QSMD003,579 3.579.545
 16
 150

QSMD003,686 3.686.000
 32
 150

QSMD004 4.000.000
 30
 150

QSMD004,096 4.096.000
 30
 150

QSMD004,194 4.194.304
 32
 150

QSMD004,915 4.915.200
 16
 120

QSMD005 5.000.000
 30
 120

QSMD006 6.000.000
 30
 100

QSMD006,144 6.144.000
 16
 100

QSMD007,372 7.372.800
 32
 100

QSMD008 8.000.000
 30
 80

QSMD009,830 9.830.400
 30
 80

QSMD010 10.000.000
 30
 70

QSMD011,059 11.059.200
 30
 70

QSMD012 12.000.000
 30
 60

QSMD012,288 12.228.000
 30
 60

QSMD015 15.000.000
 30
 60

QSMD016 16.000.000
 30
 50

QSMD020 20.000.000
 30
 40

C = Load Capacitance, RESR = Resistance of Series Resonance, Max.
Manufacturer
Abundance
http://www.aeccrystal.com
