LED Water-clear White 2600mcd 25° 3mm
Varenummer:
92-255
Varekode:
LTW420C5
Vægt:
0 g
Lagerstatus:
Ikke på lager
Gruppe:
W1267
LITEON, MIC Light-Emitting Diodes
Water-clear
White
Ultrabright
Series: LTW420_, ML37W13H_
Case: 3mm
LITEON, MIC Light-Emitting Diodes
Water-clear
White
Ultrabright
Series: LTW420_, ML37W13H_
Case: 3mm
| Technical Specifications |
| Part Nr. | Colour | WL | VA | LI | @IF | UF |
| [nm] | [°] | [mcd] | [mA] | [V] | ||
| LTW420C5 | White | - | 25 | 2600 | 20 | 3,6 |
| ML37W13H-BEC | White | - | 15 | 1200 | 20 | 3,5 |
| ML37W13H-BEF | White | - | 15 | 3500 | 20 | 3,5 |
| ML37W13H-CEC | White | - | 20 | 1200 | 20 | 3,5 |
| WL = Peak Emission Wavelength, VA = Viewing Angle, LI = Typ. Luminous Intensity, IF = Forward Current, UF = Forward Voltage | ||||||
 | ||||||
| Note |
| You will find suitable LED holders and spacing pieces in the blue "Passive and Electromechanical Components" catalogue starting at product group H3731 resp. G8293. |
|
| Terms of Delivery |
| Minimum order quantity: please see price list column "MOQ". |
|
| Manufacturer |
| http://www.cnmic.com http://optoelectronics.liteon.com |
|
