SIL-Reed Relay SPST 5V 500R Diode
Varenummer:
88-826
Varekode:
SIL05-1A72-71D
Vægt:
0 g
Lagerstatus:
Ikke på lager
Gruppe:
E4452
MEDER SIP/SIL Reed Relays
Series: SIA_, SIA_D
With or Without Diode
Contact: SPST-NO
Housing: SIP/SIL07
E4452
MEDER SIP/SIL Reed Relays
Series: SIA_, SIA_D
With or Without Diode
Contact: SPST-NO
Housing: SIP/SIL07
| Features |
| • Flux density version • High coil resistance • Loop current detection • Insulation resistance (coil/contacts): 1500V • Requires only half the PCB area of DIP/DIL relays • SIA_D_: with diode |
 |
| Technical Specifications |
| |
| Insulation Resistance (Coil/Contacts), Min.: | 1013W |
| Insulation (Coil/Contacts): | 1500V DC |
| Storage Temperature: | -35...+95°C |
| Temperature Range: | -20...+70°C |
| Operate Time (incl. Bounce Time): | 0,7ms |
| Reset Time: | 0,1ms |
| Vibration Resistance (10...2000Hz): | 20G |
| Soldering Temperature/Time: | 260°C/5s |
| |
| Contact Data |
| |
| Configuration: | SPST-NO |
| Contact Resistance, Max.: | 150mW |
| Switching Capacity, Max.: | 15W |
| Switching Voltage, Max.: | 200V DC |
| Switching Current, Max.: | 1,0A |
| Current After Closed Contact, Max.: | 1,25A |
| Breakdown Voltage: | 250V DC |
| |
| Coil Data |
| |
| Coil Type: | Polarized, Monostable |
| |
| Part Nr. | UN | UAn | UAb | RN | PN |
| [V DC] | [V DC] | [V DC] | [W] | [mW] | |
| SIA05-500 | 5 | 3,5 | 0,75 | 500 | 50 |
| SIA12-1K | 12 | 8,4 | 1,8 | 1000 | 145 |
| SIA24-2K | 24 | 16,8 | 3,6 | 2000 | 290 |
| SIA05D-500 | 5 | 3,5 | 0,75 | 500 | 50 |
| SIA12D-1K | 12 | 8,4 | 1,8 | 1000 | 145 |
| SIA24D-2K | 24 | 16,8 | 3,6 | 2000 | 290 |
| UN = Rated Voltage, UAn = Operate Voltage, UAb = Drop-Out Voltage, RN = Coil Resistance, ±10%, PN = Rated Capacity, Data Measured at 20°C | |||||
| |||||
| Approvals |
 |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces |
|
| Manufacturer |
 |
| http://www.meder.com |
|
