Reed Relay SPDT 12V 500R DIP12-1C90-51L

Varenummer:
88-819
Varekode:
DIP121C9051L
Vægt:
0 g
Lagerstatus:
Ikke på lager

kr 57,73 57.730000000000004 DKK kr 57,73 Inklusiv moms

kr 57,73 Inklusiv moms

Anmod os om en pris

v/10
Kr. 58,05
v/25
Kr. 43,94
v/100
Kr. 39,23

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/50630/image_1920?unique=864978b https://elektroniklavpris.odoo.com/web/image/product.template/50630/image_1920?unique=864978b
GROUP:E4419
Gruppe: E4419
MEDER DIP/DIL Reed Relays
Series: DIP 51L, DIP 51D
With or Without Diode
Contact: SPDT
Housing: DIP/DIL14

Features
• Fully encapsulated
• Flux sealed construction
• Plug-in a 14-pole DIP/DIL-IC socket (see note)
• TTL control possible
• DIP_51L: Low-profile
• DIP_51D: High-profile, with integrated diode
Technical Specifications
Configuration:
SPDT
Switching Capacity, Max.:
10W
Switching Voltage, Max.:
100V DC
Switching Current, Max.:
0,2A
Transport Current, Max.:
0,5A
Contact Resistance:
150mW
Insulation Resistance (Coil/Contacts):
1012W
Breakdown Voltage, Min. (Coil/Contacts):
1.500V DC
Operate Time, Max. (incl. Bounce):
2,0ms
Release Time, Max.:
2,0ms
Vibration Resistance (10...2000Hz):
20G
Temperatur Range:
-20...+70°C
Soldering Temperature/Time:
260°C/5s
Coil Data
Coil Type:
DIP_51L:
Non-Polarized, Monostable
DIP_51D:
Polarized, Monostable
Part Nr.
UN
RN
UAn
UAb
PN
 [V DC]
[W]
[V DC]
[V DC]
[mW]
DIP051C9051L5
200
3,5
0,75
125
DIP121C9051L12
500
8,4
1,8
290
DIP241C9051L24
2000
16,8
3,6
290
DIP051C9051D5
200
3,5
0,75
125
DIP121C9051D12
500
8,4
1,8
290
UN = Rated Voltage, RN = Coil Resistance, ±10%, UAn = Operate Voltage, Max., UAb = Release Voltage, Min., PN = Power Consumption, All Data Refer to 20°C
Note
• You will find suitable DIP-IC socket in product groups F3532 and F3572.
Approvals

Terms of Delivery
Minimum order quantity: 1 PKU = 10 pieces
Manufacturer

http://www.meder.com

Stregkode: 88819
Intern reference: 88819
Varekode: DIP121C9051L
