Safety Relay 24V 8A 2xNO+2xNC
Varenummer:
88-790
Varekode:
SR4D4024
Vægt:
20 g
Lagerstatus:
Ikke på lager
Gruppe:
E6813
TE Safety Relays
Series: SR4
Contact: 3xNo and 1xNC or 2xNo and 2xNC
Rated Current: 8A
Housing: 40x13x16mm
TE Safety Relays
Series: SR4
Contact: 3xNo and 1xNC or 2xNo and 2xNC
Rated Current: 8A
Housing: 40x13x16mm
| Features |
| • Relay with forcibly guided contacts according to EN50205 • 4-pole safety relay • Category of protection RTIII (wash tight) |
 |
| Application |
| Emergency shut-off, machine control, elevator and escalator control, light barrier control |
|
| Technical Specifications |
| |
| Contact | |
| SR4D4024: | 2 NO+2 NC |
| SR4M4024: | 3 NO+1 NC |
| Contact Material: | AgSnO2 |
| Rated Current: | 8A |
| Max. Switching Voltage: | 400V AC |
| Max. Switching Power: | 2000VA |
| Creepage/Clearance: | 10/10mm |
| Testing Voltage | |
| Coil/Contact: | 4000Vrms |
| Contact/Contact: | 2500Vrms |
| Opening Contact: | 1500Vrms |
| Lifetime | |
| Mechanical: | 10x106 Operations |
| Operating Temperature: | -25...+70°C |
| Weight Approx.: | 16g |
| |
| Coil Data |
| Part Nr. | UN | UAn | UAb | PN | RN |
| [V DC] | [V] | [V] | [mW] | [W] | |
| SR4D4024 | 24 | 18 | 2,4 | 800 | 720 |
| SR4M4024 | 24 | 18 | 2,4 | 800 | 720 |
| UN = Rated Voltage, UAn = Operate Voltage, UAb = Release Voltage, PN = Rated Power, RN = Coil Resistance; All Specifications Measured at 23°C | |||||
| |||||
| Norms |
| Forcibly guided contacts according to EN50205. |
|
| Approvals |
   |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
| TE Connectivity http://www.te.com |
|
