High Current Relay SPDT 30A 24V 362R Ope
Varenummer:
88-745
Varekode:
FRA24-OF
Vægt:
20 g
Lagerstatus:
Ikke på lager
Gruppe:
E6521
FIC Automotive Relays
Series: FRA2
In Wash Tight and Open Enclosures
Contact: SPDT
Rated Current: 30A
Housing: 24,0x19,0x20,0mm (26,5x22,0x22,3mm)
FIC Automotive Relays
Series: FRA2
In Wash Tight and Open Enclosures
Contact: SPDT
Rated Current: 30A
Housing: 24,0x19,0x20,0mm (26,5x22,0x22,3mm)
| Features |
| • FRA_-OF: open enclosure • FRA_-WD: wash tight enclosure in accordance with IP 67 |
 |
| Technical Specifications |
| |
| Contact: | SPDT |
| Contact Material: | AgSnO2 |
| Rated Current: | 30A |
| Max. Switching Current: | 60A |
| Max. Switching Voltage: | 75V DC |
| Max. Switching Power: | 630W |
| Operate/Release Time: | 5/3ms |
| Testing Voltage | |
| Coil/Contact: | 750V |
| Opening Contact: | 750V |
| Lifetime | |
| Mechanical: | 10x106 Operations |
| Electrical: | 1x105 Operations |
| Operating Temperature: | -40...+85 °C |
| Weight Approx. | |
| FRA_-OF: | 18g |
| FRA_-WD: | 23g |
| |
| Coil Data |
| Part Nr. | UN | Umin. | Umax. | UAb | PN | RN |
| [V DC] | [V] | [V] | [V] | [mW] | [W] | |
| FRA12-_ | 12 | 7 | 18 | 1,2 | 160 | 90 |
| FRA24-_ | 24 | 13,9 | 36 | 2,4 | 160 | 362 |
| UN = Rated Voltage, Umin. = Minimum Operating Voltage, Umax. = Maximum Operating Voltage, UAb = Release Voltage, PN = Rated Power, RN = Coil Resistance; All Specifications Measured at 20°C | ||||||
| ||||||
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces |
|
| Manufacturer |
 |
| http://www.ficrelay.com.hk |
|
