Relay SPDT 24V 1440R
Varenummer:
88-743
Varekode:
G5SB14-24
Vægt:
10 g
Lagerstatus:
Ikke på lager
Gruppe:
E6244
OMRON Signal PCB Relays
Series: G5SB
Contact: SPDT
Rated Current: 5A
Housing: 20,3x10,3x15,8mm
OMRON Signal PCB Relays
Series: G5SB
Contact: SPDT
Rated Current: 5A
Housing: 20,3x10,3x15,8mm
| Features |
| • Wash tight enclosure • Conforms to strict security regulations |
 |
| Technical Specifications |
| |
| Contact: | SPDT |
| Contact Material: | Silver Alloy |
| Rated Current (NO/NC): | 5A/3A |
| Max. Switching Current (NO/NC): | 5A/3A |
| Max. Switching Voltage: | 250V AC / 30V DC |
| Max. Switching Power | |
| NO: | 1250VA / 150W |
| NC: | 750VA / 30W |
| Operate/Release Time: | 10/5ms |
| Testing Voltage | |
| Coil/Contact: | 4000V AC |
| Contact/Contact: | 1000V AC |
| Lifetime | |
| Mechanical: | 5x106 Operations |
| Electrical: | 5x104 Operations |
| Operating Temperature: | -40...+70°C |
| Weight Approx.: | 6,5g |
| NO = Normally Open, Between Pin 2-3, NC = Normally Closed, Between Pin 2-4 | |
| |
| Coil Data |
| |||||||
| Part Nr. | UN | Umax. | UAb | UAn | IN | PN | RN |
| [V DC] | [V] | [V] | [V] | [mA] | [mW] | [W] | |
| G5SB14-12 | 12 | 13,2 | 0,6 | 9 | 33,3 | 400 | 360 |
| G5SB14-24 | 24 | 26,4 | 1,2 | 18 | 16,7 | 400 | 1440 |
| UN = Rated Voltage, Umax. = Maximum Operating Voltage, UAb = Release Voltage, UAn = Release Voltage, IN = Rated Current, PN = Rated Power, RN = Coil Resistance; All Specifications Measured at 23°C | |||||||
| |||||||
| Approvals |
  |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces |
|
| Manufacturer |
 |
| http://www.europe.omron.com |
|
Stregkode:
88743
Intern reference:
88743
Varekode:
G5SB14-24
