Relay SPDT 1A 12V 320R

Varenummer:
88-708
Varekode:
FRS1B-S-DC12V
Vægt:
0 g
Lagerstatus:
Lager: 42 stk.

kr 15,63 15.63 DKK kr 15,63 Inklusiv moms

kr 15,63 Inklusiv moms

Anmod os om en pris

v/10
Kr. 12,22
v/25
Kr. 10,39
v/100
Kr. 8,56
v/1000
Kr. 6,74

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/50532/image_1920?unique=864978b https://elektroniklavpris.odoo.com/web/image/product.template/50532/image_1920?unique=864978b

Gruppe: E6217
FIC Signal PCB Relays
Series: FRS1
Contact: SPDT
Rated Current: 1A
Housing: 16x11x11,5mm

FRS1B12

Features
• Wash tight construction
• PCB mounting, DIP/DIL pitch terminal
• Insertable in a 12-pole DIL socket
Application
General domestic appliances as well as alarm systems
Technical Specificaitons
    Contact: SPDT Contact Material: AgNi/Au Rated Current: 1A Rated Input: 1A/30V DC / 1A/125V AC Operate/Release Time: £5/5ms Testing Voltage Coil/Contact: 500V AC Contact/Contact: 500V AC Lifetime Mechanical: 10x106 Operations Electrical: 1x105 Operations Operating Temperature: -25...+75°C Weight Approx.: 4g
Coil Data
              Part Nr. UN Umin. Umax. IN PN RN   [V DC] [V] [V] [mA] [mW] [W] FRS1B12 12 9,0 13,2 37,5 450 320 FRS1B24 24 18,0 26,4 18,8 450 1280 FRS1H12 12 9,0 13,2 17,0 210 700 FRS1H24 24 18,0 26,4 8,6 210 2800
UN = Rated Voltage, Umin. = Minimum Operating Voltage, Umax. = Maximum Operating Voltage, IN = Rated Current, PN = Rated Power, RN = Coil Resistance; All Specifications Measured at 20°C
Safety Note
When switching from mains voltage the valid VDE regulations (VDE0110) must be observed. In order to exclude a safety risk, the insulation voltage between coil and contact should amount to at least 4000V AC
Approvals
Additional Products
Also available on request (minimum order quantity 500 pieces, delivery time: approx. 12 weeks):
• Relays with rated voltages of 3,0 to 9,0V (as well as standard and also sensitive operation use)
• Relays for rated current (ohmic load): 5A/24V DC, 3A/110V AC
Terms of Delivery
Minimum order quantity: 1 PKU = 10 pieces
Manufacturer
http://www.ficrelay.com.hk
Kontakt os

Stregkode: 88708
Intern reference: 88708
Varekode: FRS1B-S-DC12V
