Oscillator 1,8432MHz DIL14 CMOS/TTL

Varenummer:
86-084
Varekode:
QOM001,843
Vægt:
0 g
Lagerstatus:
Ikke på lager

kr 21,00 21.0 DKK kr 21,00 Inklusiv moms

kr 21,00 Inklusiv moms

Anmod os om en pris

v/10
Kr. 19,69
v/25
Kr. 16,41
v/100
Kr. 13,12

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/29045/image_1920?unique=23de69a https://elektroniklavpris.odoo.com/web/image/product.template/29045/image_1920?unique=23de69a
Features
• Suitable for CMOS and TTL
• Consisting of piezoelectric resonator and oscillator circuit
• High reliability due to hermetically sealed metal housing
Technical Specifications
Frequency Range:
 1,843MHz...64MHz
Frequency Stability:
 ±100ppm
Temperature Range:
 0...+70°C
Storage Temperature:
 -55...+125°C
Operating Voltage [VDD]:
 5± 0,5V DC
Current Requirement, Max.
1,843...20MHz:
 20mA
24...40MHz:
 30mA
50...70MHz:
 60mA
Symmetry at 50% VDDtight:
 45...55%
Output Voltage, Max.
"1"-Level:
 +4,5V(90% VDD)
"0"-Level:
 +0,5V(10% VDD)
Output Load:
 15pF Typ. or 10 TTL Max.
Manufacturer
Abundance
http://www.aeccrystal.com
