Oscillator 1,8432MHz DIL8 CMOS/TTL

Varenummer:
86-074
Varekode:
QOS001,843D8
Vægt:
0 g
Lagerstatus:
Ikke på lager

kr 31,20 31.2 DKK kr 31,20 Inklusiv moms

kr 31,20 Inklusiv moms

Anmod os om en pris

v/10
Kr. 29,25
v/25
Kr. 24,38
v/100
Kr. 19,50

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/29035/image_1920?unique=23de69a https://elektroniklavpris.odoo.com/web/image/product.template/29035/image_1920?unique=23de69a
Features
• Suitable for CMOS/TTL or CMOS
• Cylindrical AT-cut crystal unit built-in, thus assuring high reliability
• Use of CMOS OC enable reduction of current consumption
• Output with "stand-by" function
Technical Specifications
  SG-531P
 SG-531PH
Frequency Range [MHz]:
 1,8432...24
 30...48
Frequency Stability [ppm]:
 ±100
 ±100
Operating Voltage [VDD]:
 5±0,5
 5±0,5
Max. Supply Voltage [VDD-GND]:
 -0,3...+7
 -0,5...+7
Output Voltage

VOH1) [V], Min.:
 VDD-0,4.
 VDD -0,4min.
VOL2) [V], Max.:
 0,4max.
 0,4max.
Output Current

IOH1) [mA]:
 -0,4
 -4
IOL2) [mA]:
 16
 4
Temperature Range [°C]:
 -20...+70
 -20...+70
Temperature Range [°C]:
 -55...+125
 -55...+100
Rise Time/Fall Time [ns]:
 8
 7
Aging, Max. [ppm/Year]:
 5
 5
Soldering Temperature, Max.:
 �260°C/10s
 �260°C/10s
Shock Resistance [ppm]:
 ±20
 ±20
Suitable for:
 CMOS, TTL
 CMOS
1) VOH, IOH ="1"-Level, 2) VOL, IOL = "0"-Level
Manufacturer

http://www.epson-electronics.de
