SMD Crystal 40.000.000Hz 3rd
Varenummer:
86-048
Varekode:
QMIM040-SMD
Vægt:
0 g
Lagerstatus:
Ikke på lager
| Technical Specifications |
 | |
| Frequency: | 4...40MHz |
| Frequency Tolerance (25°C): | �50ppm |
| Shunt Capacitance, Max.: | 5pF |
| Temperature Range: | -20...+70°C |
| Frequency Stability in Operating Temperature | |
| 5,5MHz: | �50ppm |
| >5,5MHz: | �30ppm |
| Insulation Resistance, Min: | 500MW |
| Load (Recommended): | 100�W |
| Aging: | �5ppm/Year |
| Shock Resistance, Max.: | �10ppm |
| |
| Part Nr. | Frequency | C | RESR | Type |
| � | [Hz] | [pF] | W | � |
| QMIM004-SMD | 4.000.000 | 16 | 150 | Fundamental |
| QMIM004.915-SMD | 4.915.200 | 16 | 150 | Fundamental |
| QMIM006-SMD | 6.000.000 | 16 | 80 | Fundamental |
| QMIM008-SMD | 8.000.000 | 16 | 80 | Fundamental |
| QMIM010-SMD | 10.000.000 | 16 | 60 | Fundamental |
| QMIM011.059-SMD | 11.059.200 | 16 | 60 | Fundamental |
| QMIM012-SMD | 12.000.000 | 16 | 50 | Fundamental |
| QMIM016-SMD | 16.000.000 | 16 | 40 | Fundamental |
| QMIM024-SMD | 24.000.000 | 16 | 40 | Fundamental |
| QMIM040-SMD | 40.000.000 | 16 | 80 | 3. Harmonic |
| C = Load Capacitance, RESR = Resistance of Series Resonance, Max. | ||||
| ||||
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 5 pieces |
|
| Manufacturer |
 |
| http://www.epson-electronics.de |
|
