SMD Crystal 10.000.000Hz
Varenummer:
86-041
Varekode:
QMIM010-SMD
Vægt:
0 g
Lagerstatus:
Ikke på lager
Gruppe:
D9124
EPSON SMD Quartz Crystals
Series: MA505
In Plastic Housing
Frequency: 4...24MHz
EPSON SMD Quartz Crystals
Series: MA505
In Plastic Housing
Frequency: 4...24MHz
| Technical Specifications |
 | |
| Frequency: | 4...24MHz |
| Frequency Tolerance (25°C): | ±50ppm |
| Shunt Capacitance, Max.: | 5pF |
| Temperature Range: | -20...+70°C |
| Frequency Stability in Operating Temperature | |
| 5,5MHz: | ±50ppm |
| >5,5MHz: | ±30ppm |
| Insulation Resistance, Min: | 500MW |
| Load (Recommended): | 100µW |
| Aging: | ±5ppm/Year |
| Shock Resistance, Max.: | ±10ppm |
| |
| Part Nr. | Frequency | C | RESR | Type |
| [Hz] | [pF] | W | ||
| QMIM004-SMD | 4.000.000 | 16 | 150 | Fundamental |
| QMIM004.915-SMD | 4.915.200 | 16 | 150 | Fundamental |
| QMIM006-SMD | 6.000.000 | 16 | 80 | Fundamental |
| QMIM008-SMD | 8.000.000 | 16 | 80 | Fundamental |
| QMIM010-SMD | 10.000.000 | 16 | 60 | Fundamental |
| QMIM011.059-SMD | 11.059.200 | 16 | 60 | Fundamental |
| QMIM012-SMD | 12.000.000 | 16 | 50 | Fundamental |
| QMIM016-SMD | 16.000.000 | 16 | 40 | Fundamental |
| QMIM024-SMD | 24.000.000 | 16 | 40 | Fundamental |
| C = Load Capacitance, RESR = Resistance of Series Resonance, Max. | ||||
| ||||
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 5 pieces |
|
| Manufacturer |
 |
| http://www.epson-electronics.de |
|
Stregkode:
86041
Intern reference:
86041
Varekode:
QMIM010-SMD
