Kvarts krystal 6.400.000Hz HC-49/U
Varenummer:
85-992
Varekode:
QM006,400
Vægt:
0 g
Lagerstatus:
Lager: 12 stk.
| Technical Specifications |
 | |
| Operating Temperature Range: |
-10...+60°C |
| Frequency Tolerance (25°C): |
±30ppm |
| Shunt Capacitance, max.: |
7pF |
| Drive Level: |
1,0mW |
| Insulation Resistance (100V DC): |
>500MW |
| Aging: |
±5ppm/Year |
| |
| Part Nr. |
Frequency |
C |
RESR |
Type |
| [Hz] |
[pF] |
W |
||
| QM001,843 | 1.843.200 |
30 |
600 |
fundamental |
| QM002 | 2.000.000 |
30 |
550 |
fundamental |
| QM002,457 | 2.457.600 |
30 |
350 |
fundamental |
| QM003 | 3.000.000 |
32 |
150 |
fundamental |
| QM003,276 | 3.276.800 |
12,5 |
150 |
fundamental |
| QM003,579 | 3.579.545 |
16 |
100 |
fundamental |
| QM003,686 | 3.686.400 |
16 |
100 |
fundamental |
| QM004 | 4.000.000 |
30 |
90 |
fundamental |
| QM004,096 | 4.096.300 |
30 |
90 |
fundamental |
| QM004,194 | 4.194.304 |
32 |
90 |
fundamental |
| QM004,336 | 4.336.180 |
16 |
90 |
fundamental |
| QM004,433 | 4.433.618 |
16 |
100 |
fundamental |
| QM004,915 | 4.915.200 |
16 |
90 |
fundamental |
| QM005 | 5.000.000 |
30 |
80 |
fundamental |
| QM005,068 | 5.068.000 |
30 |
80 |
fundamental |
| QM006 | 6.000.000 |
30 |
60 |
fundamental |
| QM006,144 | 6.144.000 |
16 |
60 |
fundamental |
| QM006,400 | 6.400.000 |
30 |
60 |
fundamental |
| QM006,553 | 6.553.600 |
30 |
60 |
fundamental |
| QM007,372 | 7.372.800 |
32 |
60 |
fundamental |
| QM008 | 8.000.000 |
30 |
50 |
fundamental |
| QM008,867 | 8.867.238 |
30 |
50 |
funfamental |
| QM009,216 | 9.216.000 |
30 |
45 |
fundamental |
| QM009,830 | 9.830.400 |
30 |
45 |
fundamental |
| QM010 | 10.000.000 |
30 |
40 |
fundamental |
| QM010,240 | 10.240.000 |
30 |
40 |
fundamental |
| QM010,700 | 10.700.000 |
30 |
40 |
fundamental |
| QM011,000 | 11.000.000 |
30 |
40 |
fundamental |
| QM011,0592 | 11.059.200 |
30 |
40 |
fundamental |
| QM012 | 12.000.000 |
30 |
35 |
fundamental |
| QM014,318 | 14.318.180 |
30 |
35 |
fundamental |
| QM015 | 15.000.000 |
30 |
30 |
fundamental |
| QM016 | 16.000.000 |
30 |
30 |
fundamental |
| QM018 | 18.000.000 |
30 |
25 |
fundamental |
| QM018,432 | 18.432.000 |
30 |
25 |
fundamental |
| QM020 | 20.000.000 |
30 |
25 |
fundamental |
| QM024-FUND | 24.000.000 |
30 |
25 |
fundamental |
| QM024 | 24.000.000 |
30 |
50 |
3. harmonic |
| QM027 | 27.000.000 |
32 |
50 |
3. harmonic |
| QM032 | 32.000.000 |
* |
50 |
3. harmonic |
| QM036 | 36.000.000 |
* |
50 |
3. harmonic |
| QM048 | 48.000.000 |
* |
50 |
3. harmonic |
| C = Load Capacitance, RESR = Resistance of Series Resonance, max., * = Infinitely | ||||
| ||||
Stregkode:
226-1667
Intern reference:
85992
Varekode:
QM006,400
