El-Capacitor 4700uF/40V-21x36mm
Varenummer:
85-883
Varekode:
CAX04700/40
Vægt:
20 g
Lagerstatus:
Ikke på lager
Gruppe: C6625
F&T Electrolytic Capacitors
Series: A
Axial
Style: Bulk
Rated Voltage: 40V DC
Tolerance: 20%
Temperature Range: -40...+105°C
| Features |
| • Polarized • High ripple current • Max. Reverse Voltage: 2V |
 |
| Technical Specifications |
| Part Nr. | C | tand | RESR | ZMax | D | L | d | CAX_ | [µF] | [%] | W | W | [mm] | [mm] | [mm] | 00470/40 | 470 | 12 | 0,33 | 0,30 | 10 | 25 | 0,8 | 01000/40 | 1000 | 12 | 0,225 | 0,25 | 12 | 30 | 0,8 | 02200/40 | 2200 | 15 | 0,15 | 0,13 | 18 | 30 | 0,8 | 04700/40 | 4700 | 15 | 0,09 | 0,06 | 21 | 36 | 0,8 | ||||||||
| C = Rated Capacitance, tan d = Dissipation Factor (100Hz, 20°C), RESR = ESR (100Hz, 20°C), ZMax = Impedance (10kHz, 20°C) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Norms |
| IEC 384-4 |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 25 pieces 2200µF...4700µF: 1 PKU = 10 pieces Form of delivery: Bulk |
|
| Manufacturer |
 |
| http://www.ftcap.de |
|
Stregkode:
85883
Intern reference:
85883
Varekode:
CAX04700/40
