El-Capacitor 470µF/16V 10x13 P5
Varenummer:
85-703
Varekode:
CS0470/16-P5
Vægt:
0 g
Lagerstatus:
Ikke på lager
Gruppe: C6351
JAMICON, CAPXON Electrolytic Capacitors
Series: SK/GR
Radial
Style: Bulk
Rated Voltage: 16V DC
Tolerance: 20%
Temperature Range: -40...+85°C
| Technical Specifications |
 |
|||||||||
| Rated Voltage: | 16V DC | Capacitance Tolerance: | ±20% | Temperature Range: | -40...+85°C | Leakage Current: | IL£0,01xCxUN or 4µA | ||
|
|||||||||
| Part Nr. | C | IR | D | L | P | d | [µF] | [mA] | [mm] | CS0470/16 | 470 | 480 | 10 | 13 | 5,0 | 0,6 | CS1000/16 | 1000 | 870 | 10 | 21 | 5,0 | 0,6 | CS2200/16 | 2200 | 1330 | 13 | 21 | 5,0 | 0,6 | CS4700/16 | 4700 | 2050 | 16 | 32 | 7,5 | 0,8 | |||||||||||
| C = Rated Capacitance, IR = Ripple Current (85°C, 120Hz), P = Pitch | ||||||||||||||||||||||||||||||||||||||||||||||||
|
||||||||||||||||||||||||||||||||||||||||||||||||
| Note |
| • Taped 25V capacitors for temperature ranges up to 105°C are available in this catalogue from product group C6380. |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 25 pieces Form of delivery: Bulk |
|
| Manufacturer |
  |
| http://www.jamicon.com.tw http://www.capxongroup.com |
|
Stregkode:
85703
Intern reference:
85703
Varekode:
CS0470/16-P5
