SMD Tantalum Capacitor 33uF 16V D
Varenummer:
85-683
Varekode:
CTUF033D-SMD
Vægt:
0 g
Lagerstatus:
Ikke på lager
Gruppe: C6161
KEMET SMD Tantalum Capacitors
Series: B45197A
Low ESR, SpeedPower
Rated Voltage: 10...35V DC
Tolerance: 10%
Housing: C, D, E
| Features |
| • Stable temperature and frequency characteristics • Low leakage current, low dissipation factor • High resistance to shock and vibration • Flame retardant plastic case UL94V-0 • Telecommunications, measuring and control engineering, automotive electronics, DC/DC converters |
 |
| Technical Specifications |
|
|||||||||||||||
| Technology: | Ta-MnO2 | Rated Voltage: | see Table | Capacitance Tolerance: | ±10% | Temperature Range: | -55...+85°C | With Voltage Reduction: | +85...+125°C | Climatic Category: | 55/125/56 | Service Life: | >500000h | ||
|
|||||||||||||||
| Part Nr. | C | UN | U125 | RESR | ILK | IAC | Chip | B45197A-_ | [µF] | [V DC] | [V DC] | [mW] | [µA] | [A] | Size | 100D | 100 | 10 | 6,3 | 100 | 10 | 1,22 | D | 220E | 220 | 10 | 6,3 | 100 | 22 | 1,28 | E | 330E | 330 | 10 | 6,3 | 100 | 33 | 1,28 | E | 033D | 33 | 16 | 10 | 200 | 5,3 | 0,87 | D | 047D | 47 | 16 | 10 | 175 | 7,5 | 0,93 | D | 100E | 100 | 16 | 10 | 100 | 16 | 1,28 | E | 068E | 68 | 20 | 13 | 200 | 14 | 0,91 | E | 004.7C | 4,7 | 25 | 16 | 525 | 1,2 | 0,46 | C | 022D | 22 | 25 | 16 | 230 | 5,5 | 0,81 | D | 010D | 10 | 35 | 23 | 260 | 3,5 | 0,76 | D | 022E | 22 | 35 | 23 | 260 | 7,7 | 0,80 | E | ||||||||
| C = Capacitance, UN = Rated Voltage DC 35 to +85°C, U125 = Decreased Rated Voltage DC to 125°C, RESR = Equivalent Series Resistance (20°C, 100 kHz), ILK=Leakage Current (20°C, UN, 5Min), IAC = Alternating Current (20°C, 100kHz) | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Dimensions |
| Chip | L±0,3 | W±0,3 | H±0,3 | L2typ. | W2±0,1 | H2typ. | P±0,3 | [mm] | C | 6,0 | 3,2 | 2,5 | 5,8 | 2,2 | 1,5 | 1,3 | D | 7,3 | 4,3 | 2,8 | 7,1 | 2,4 | 1,6 | 1,3 | E | 7,3 | 4,3 | 4,1 | 7,1 | 2,4 | 1,6 | 1,3 | |||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||
| Labelling |
| Manufacturer, polarity bar (positive pole marking), capacitance, date code, rated voltage |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces Form of delivery: orders with complete reel: chip size C, D: 750 pieces, E: 400 pieces on 12mm reel; for smaller quantities 10 pieces on tape segment without leader tape and reel. |
|
| Manufacturer |
 |
| http://www.kemet.com |
|
Stregkode:
85683
Intern reference:
85683
Varekode:
CTUF033D-SMD
