Tantalum Capacitor 3,3uF 35V P2,54
Varenummer:
85-636
Varekode:
CTUF003,3GM1
Vægt:
0 g
Lagerstatus:
Ikke på lager
Features
| • Tantalum solid capacitors with yellow epoxy marked by laser • Flame-retardant material • Radial leads |
 |
| Technical Specifications |
|
|
| Rated Voltage: | 35V DC |
| Temperature Range: | -55...+85°C1) |
| 1) Up to 125°C with decreased voltage, see table |
|
|
|
| Part Nr. | C | U125 | IL | P | DMax. | HMax. |
| [µF] | [V DC] | [µA] | [mm] | [mm] | [mm] | |
| CTL000.47G | 0,47 | 20 | 0,165 | 2,54 | 4,5 | 7,0 |
| CTL001G | 1,0 | 20 | 0,35 | 2,54 | 4,5 | 7,0 |
| CTL001.5G | 1,5 | 20 | 0,5 | 2,54 | 4,5 | 7,0 |
| CTL002.2G | 2,2 | 20 | 0,5 | 2,54 | 5,0 | 8,0 |
| CTL003.3G | 3,3 | 20 | 0,5 | 2,54 | 5,0 | 8,0 |
| CTL004.7G | 4,7 | 20 | 0,5 | 2,54 | 5,5 | 9,5 |
| CTL010G | 10 | 20 | 0,5 | 2,54 | 6,5 | 11,0 |
| CTL022G | 22 | 20 | 0,5 | 5,08 | 8,5 | 13,0 |
| C = Capacitance, U125 = Decreased DC Voltage at Operating Temperature up to 125°C, IL = DC Leakage at 25°C, P = Pitch | ||||||
|
||||||
| Norms |
| IEC384-15-3, IECQ QC300201/US0003, SJ/T10856-96 |
|
Stregkode:
85636
Intern reference:
85636
Varekode:
CTUF003,3GM1
