Tantalum Capacitor 22uF 25V P2,5

Varenummer:
85-624
Varekode:
CTUF022FM1
Vægt:
0 g
Lagerstatus:
Ikke på lager

kr 20,13 20.13 DKK kr 20,13 Inklusiv moms

kr 20,13 Inklusiv moms

Anmod os om en pris

v/10
Kr. 21,05
v/100
Kr. 17,12
v/1000
Kr. 12,79

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/28593/image_1920?unique=8b93c9a https://elektroniklavpris.odoo.com/web/image/product.template/28593/image_1920?unique=8b93c9a

Gruppe: C6140
KEMET Tantalum Solid Capacitors
Series: T350
Style: Taped
Rated Voltage: 16...35V DC
Tolerance: 20%
Pitch: 2,54mm

Features
• Tantalum solid capacitors with orange coloured epoxy
• Self-extinguishing
• Self-insulating cases which are resistant to shock and vibration
• Radial leads
Technical Specifications
    Rated Voltage: see Table Surge Voltage: 1,3xUN Capacitance Tolerance: ±20% Temperature Range: -55°C...+85°C1)
1) Up to 125°C with decreased voltage, see table
                  Part Nr. C UN U125 IL tan d RM D H _-GURT [µF] [V DC] [V DC] [µA] [%] [mm] [mm] [mm] CTUF002.2D 2,2 16 10 0,5 5 2,54 4,5 7,1 CTUF003.3D 3,3 16 10 0,5 5 2,54 4,5 7,1 CTUF004.7D 4,7 16 10 0,6 5 2,54 4,5 7,6 CTUF010D 10,0 16 10 1,3 6 2,54 5,5 8,9 CTUF022D 22,0 16 10 2,6 6 2,54 6,0 9,9 CTUF002.2F 2,2 25 16 0,5 5 2,54 4,5 7,6 CTUF004.7F 4,7 25 16 0,9 5 2,54 5,0 8,4 CTUF010F 10,0 25 16 2,0 6 2,54 5,5 8,9 CTUF022F 22,0 25 16 4,4 6 2,54 7,6 11,9 CTUF001G 1,0 35 23 0,5 3 2,54 4,5 7,1 CTUF002.2G 2,2 35 23 0,6 5 2,54 5,0 8,4 CTUF004.7G 4,7 35 23 1,3 5 2,54 5,5 8,9 CTUF010G 10,0 35 23 2,8 6 2,54 6,3 10,2
C= Capacitance, UN = DC Voltage Rating, U125 = Decreased DC Voltage at Operating Temperature up to 125°C, IL = Leakage at 25°C, tan d = Max. Dissipation Factor at 25°C and 120Hz, P = Pitch
Terms of Delivery
Minimum order quantity: 1 PKU = See table with "Tape Segment"
Articles in bold print in stock, other articles available on request, delivery time approx. 4 weeks.
        Tape Segment1) Reel   (= Minimum Order Quantity) For Orders of   [Pieces] [Pieces] CTUF002.2D-GURT 100 1500 CTUF003.3D-GURT 100 2500 CTUF004.7D-GURT 100 1500 CTUF010D-GURT 100 2000 CTUF022D-GURT 100 2500 CTUF002.2F-GURT 100 1500 CTUF004.7F-GURT 100 1500 CTUF010F-GURT 100 1000 CTUF022F-GURT 100 800 CTUF001G-GURT 100 2500 CTUF002.2G-GURT 100 1500 CTUF004.7G-GURT 100 1000 CTUF010G-GURT 100 1500
1) = Tape Segment without Leader Tape and Reel
Manufacturer
http://www.kemet.com
