• Polypropylene film. Aluminium layer plates deposited by evaporation under vacuum, tinned wire leads
• Box material is solvent resistant and flame retardant (UL94V-0)
|
 |
|
|
|
Rated Voltage (UN):
|
See Table
|
Test Voltage (2s; 25±5°C):
|
1,6xUN
|
Capacitance Tolerance (1kHz):
|
±10%
|
Temperature Range:
|
-55...+105°C
|
Climatic Category (IEC60068-1):
|
55/100/56
|
Insulation Resistance
|
C�30nF:
|
³1x105 MW(5x105MW*)
|
C³330nF:
|
³30000s (150000s*)
|
* = Typical Value
|
|
|
|
|
|
|
|
Part Nr.
|
CN
|
UN
|
Ueff
|
du/dt
|
K0
|
| |
[nF]
|
[V =]
|
[V AC]
|
[V/μS]
|
[V2/μs]
|
| C75NF100-400 |
100
|
400
|
220
|
300
|
240 E3
|
| C75NF220-400 |
220
|
400
|
220
|
300
|
240 E3
|
| C75NF330-400 |
330
|
400
|
220
|
300
|
240 E3
|
| C75NF470-400 |
470
|
400
|
220
|
180
|
144 E3
|
| C75NF680-400 |
680
|
400
|
220
|
180
|
144 E3
|
| C75UF001,0-400 |
1000
|
400
|
220
|
180
|
144 E3
|
| C75UF001-630R27 |
1000
|
630
|
250
|
180
|
227 E3
|
| C75UF001,5-400 |
1500
|
400
|
220
|
130
|
104 E3
|
| C75UF002,2-400 |
2200
|
400
|
220
|
130
|
104 E3
|
| C75UF004,7-630 |
4700
|
630
|
250
|
180
|
227 E3
|
CN = Rated Capacitance, UN = Rated Voltage DC, Ueff = RMS Voltage, du/dt = Pulse Strength, Max., K0 = Pulse Characteristic
|
|
|
|
|
|
|
|
Part Nr.
|
B
|
H
|
L
|
P
|
Ø
|
| |
[mm]
|
[mm]
|
[mm]
|
[mm]
|
[mm]
|
| C75NF100-400 |
5
|
11
|
18
|
15
|
0,8
|
| C75NF220-400 |
7,5
|
13,5
|
18
|
15
|
0,8
|
| C75NF330-400 |
10
|
16
|
18
|
15
|
0,8
|
| C75NF330-400R22 |
6
|
15
|
26,5
|
22,5
|
0,8
|
| C75NF470-400 |
7
|
16
|
26,5
|
22,5
|
0,8
|
| C75NF680-400 |
10
|
18,5
|
26,5
|
22,5
|
0,8
|
| C75UF001,0-400 |
11
|
20
|
26,5
|
22,5
|
0,8
|
| C75NF001-630R27 |
13
|
22
|
32
|
27,5
|
0,8
|
| C75UF001,5-400 |
13
|
22
|
32
|
27,5
|
0,8
|
| C75UF002,2-400 |
15
|
24,5
|
32
|
27,5
|
0,8
|
| C75UF004,7-630 |
20
|
40
|
41,5
|
37,5
|
0,8
|
|
Dissipation Factor Tan d (25 ±5°C)
|
|
|
|
|
|
kHz
|
C�100nF
|
100nFC�1μF
|
1μFC�4,7μF
|
C>4,7μF
|
| 1 |
�4x10-4
|
�5x10-4
|
�6x10-4
|
�10x10-4
|
| 10 |
�6x10-4
|
�8x10-4
|
-
|
-
|
| 100 |
�25x10-4
|
-
|
-
|
-
|
|
| Labelling |
Manufacturer logo, series, dielectric code (MKP), rated capacitance, tolerance, DC rated voltage, manufacturing date code
|
|
|
