MKP Capacitor 10nF 630V 10% P7,5
Varenummer:
85-553
Varekode:
C75NF010-630
Vægt:
0 g
Lagerstatus:
Ikke på lager
Gruppe:
C5721
KEMET/ARCOTRONICS MKP Metallized Film Capacitors
Series: R.75
Multilayer Technology
Style: Bulk
Rated Voltage: 630/1000V DC
Tolerance: 10%
Pitch: 7,5mm
KEMET/ARCOTRONICS MKP Metallized Film Capacitors
Series: R.75
Multilayer Technology
Style: Bulk
Rated Voltage: 630/1000V DC
Tolerance: 10%
Pitch: 7,5mm
| Features |
| • Polypropylene film. Aluminium layer plates deposited by evaporation under vacuum, tinned wire leads • Box material is solvent resistant and flame retardant according to UL94V-0 • Low attenuation |
 |
| Technical Specifications |
| |
| Rated Voltage (UN): | See Table |
| Test Voltage (2s; 25±5°C): | 1,6xUN |
| Capacitance Tolerance (1 kHz): | ±10% |
| Temperature Range: | -55...+105°C |
| Climatic Category (IEC60068-1): | 55/100/56 |
| Insulation Resistance | |
| C£330nF: | ³1x105MW(5x105MW*) |
| C>330nF: | ³30000s(150000s*) |
| * = Typical Value | |
| |
| Part Nr. | CN | UN | Ueff | du/dt | K0 |
| [nF] | [V DC] | [V AC] | [V/µs] | [V2/µs] | |
| C75NF001.0-1000 | 1,0 | 1000 | 400 | 4000 | 8,0 E6 |
| C75NF002.2-1000 | 2,2 | 1000 | 400 | 4000 | 8,0 E6 |
| C75NF003.3-630 | 3,3 | 630 | 250 | 2400 | 760 E3 |
| C75NF004.7-630S | 4,7 | 630 | 250 | 4700 | 760 E3 |
| C75NF006.8-630 | 6,8 | 630 | 250 | 2400 | 760 E3 |
| C75NF010-630 | 10,0 | 630 | 250 | 2400 | 760 E3 |
| CN = Rated Capacitance, UN = Rated Voltage DC, Ueff = RMS Voltage, du/dt = Pulse Strength, Max., K0 = Pulse Characteristic | |||||
| |||||
| Dimensions |
| Part Nr. | B | H | L | RM | Ø |
| [mm] | [mm] | [mm] | [mm] | [mm] | |
| C75NF001.0-630 | 4,0 | 9,0 | 10,0 | 7,5 | 0,5 |
| C75NF001.0-1000 | 3,0 | 8,0 | 10,8 | 7,5 | 0,5 |
| C75NF002.2-1000 | 4,0 | 9,0 | 10,0 | 7,5 | 0,5 |
| C75NF003.3-630 | 4,0 | 9,0 | 10,0 | 7,5 | 0,5 |
| C75NF004.7-630S | 4,0 | 9,0 | 10,0 | 7,5 | 0,5 |
| C75NF006.8-630 | 4,0 | 9,0 | 10,0 | 7,5 | 0,5 |
| C75NF010-630 | 5,0 | 10,5 | 10,0 | 7,5 | 0,5 |
| |||||
| Norms |
| IEC60384-16 Quality assurance:EN ISO9001, QS 9000 |
|
| Labelling |
| Manufacturer logo, series, dielectric code (MKP), rated capacitance, tolerance, DC rated voltage, manufacturing date code |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 50 pieces Form of delivery:Bulk |
|
| Manufacturer |
 |
| http://www.kemet.com |
|
