  6. MKT Capacitor 1uF 63V 10% P5,08

MKT Capacitor 1uF 63V 10% P5,08

Varenummer:
85-478
Varekode:
IRD001UF
Vægt:
0 g
Lagerstatus:
Ikke på lager

kr 3,83 3.83 DKK kr 3,83 Inklusiv moms

kr 3,83 Inklusiv moms

Anmod os om en pris

v/10
Kr. 2,19
v/25
Kr. 1,96

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/28448/image_1920?unique=14ab7d4 https://elektroniklavpris.odoo.com/web/image/product.template/28448/image_1920?unique=14ab7d4
Features
• Metallized polyester film
• High pulse rating
• Self-healing properties
• Low inductance
Technical Specifications
Rated Voltage (UN):
 See Table
Test Voltage (2s, 25°C):
 1,6xUN
Capacitance Tolerance:
 ±10%
Temperature Range:
 -55...+100°C
Climatic Category
 55/100/56
Tangent of Loss Angle d
(1kHz, 1000h):
 �80x10-4
Insulation Resistance
CN�30nF:
 15GW
CN>30nF:
 Ri xCN³5000s
Pulse Rise Time, Max. (du/dt)
63V:
 150V/μs
100V:
 200V/μs
Part Nr.
 CN
 UN
 L
 H
 e
  [nF]
 [V=]
 [mm]
 [mm]
 [mm]
IRD001NF 1
 100
 7,5
 6,5
 2,5
IRD002,2NF 2,2
 100
 7,5
 6,5
 2,5
IRD003,3NF 3,3
 100
 7,5
 6,5
 2,5
IRD004,7NF 4,7
 100
 7,5
 6,5
 2,5
IRD006,8NF 6,8
 100
 7,5
 6,5
 2,5
IRD010NF 10
 100
 7,5
 6,5
 2,5
IRD022NF 22
 100
 7,5
 6,5
 2,5
IRD033NF 33
 63
 7,5
 6,5
 2,5
IRD047NF 47
 63
 7,5
 6,5
 2,5
IRD068NF 68
 63
 7,5
 6,5
 2,5
IRD100NF 100
 63
 7,5
 6,5
 2,5
IRD150NF 150
 63
 7,5
 8,0
 3,2
IRD220NF 220
 63
 7,5
 8,0
 3,2
IRD470NF 470
 63
 7,5
 8,0
 5,0
IRD680NF 680
 63
 7,5
 9,6
 6,0
IRD001UF 1000
 63
 7,5
 8,0
 5,0
CN = Rated Capacitance, UN = Rated Voltage DC
Norms
CET384-1, CECC30000, UTE83100
Sectional specifications: CET384-2, CECC30400, UTE83151
Labelling
Thomson logo, rated capacitance, tolerance (according to EIA-Code), rated voltage (V DC)
Manufacturer
AVX
http://www.avx.com
