U-Ref 5,000V +-1% 20ppm TO92
Varenummer:
82-102
Varekode:
LM336Z-5.0/NOPB
Vægt:
0 g
Lagerstatus:
Ikke på lager
The LM336Z-5.0/NOPB is an Integrated Circuit, precision 5.0V shunt regulator diode. This monolithic IC voltage references operate as a low temperature coefficient 5.0V Zener with 0.6R dynamic impedance. A third terminal on the LM136-5.0 allows the reference voltage and temperature coefficient to be trimmed easily. The LM136-5.0 series is useful as a precision 5.0V low voltage reference for digital voltmeters, power supplies or op amp circuitry. The 5.0V makes it convenient to obtain a stable reference from low voltage supplies. Further, since the LM136-5.0 operates as a shunt regulator, it can be used as either a positive or negative voltage reference.
- Low temperature coefficient
- Guaranteed temperature stability
- Easily trimmed for minimum temperature drift
- Fast turn-on
- Wide operating current of 600µA to 10mA
- 0.6R Dynamic impedance
- ±1% Initial tolerance
-
Nominel spænding 5V Kapslingstype TO-92 Referencetype Præcision Nøjagtighed initial 1% Monteringstype Hulmontering Topologi Shunt Udgangsstrøm maks. 10mA Udgangsspænding min. 4,8 V Udgangsspænding maks. 5,2 V Benantal 3 Belastningsregulering 20 mV Dimensioner 5.2 x 4.19 x 5.2mm Højde 5.2mm Driftstemperatur min. 0 °C Bredde 4.19mm Længde 5.2mm Driftstemperatur maks. +70 °C
Stregkode:
533-5806
Intern reference:
82102
Varekode:
LM336Z-5.0/NOPB
