U-Reg -15V 1A TO220
Varenummer:
81-947
Varekode:
L7915CV
Vægt:
0 g
Lagerstatus:
Ikke på lager
- TDB2915SP MC7915C TS7915CZ
- IC, V REG -15V, 7915, TO-220-3
- Primary Input Voltage: -23V
- Output Voltage Fixed: -15.6V
- Dropout Voltage Vdo: 2V
- No. of Outputs: 1
- No. of Pins: 3
- Output Current: 1A
- Voltage Regulator Case Style: TO-220
- Operating Temperature Range: -20°C to +85°C
- SVHC: No SVHC (18-Jun-2012)
- Accuracy %: 4%
- Base Number: 79
- External Depth: 4.826mm
- External Length / Height: 29.620mm
- External Width: 10.500mm
- IC Generic Number: 7915
- IC Package (Case style): TO-220
- Input Voltage: -35V
- Input Voltage Max: -17V
- Input Voltage Min: -35V
- Lead Spacing: 2.715mm
- Logic Function Number: 7915
- Operating Temperature Max: 85°C
- Operating Temperature Min: -20°C
- Operating Voltage Tolerance +: 4%
- Output Current Max: 1A
- Output Voltage: -15.6V
- Output Voltage Max: -15.6V
- Package / Case: TO-220
- Supply Voltage Max: -30V
- Supply Voltage Min: -17.5V
- Termination Type: Through Hole
- Voltage: -15V
- Voltage Drop @ Rated Current: 2V
- Voltage Regulator Type: Negative Fixed
Stregkode:
686-9795
Intern reference:
81947
Varekode:
L7915CV
