Hall Switch Bip -20/+20mT PSSO3-2
Varenummer:
81-877
Varekode:
TLE4935L
Vægt:
0 g
Lagerstatus:
Ikke på lager
| Technical Specifications |
| TLE_ | Pol | Bop | BRP | DB |
| � | � | [mT] | [mT] | [mT] |
| 4905G-PB | Unip | 7...18 | 5...16 | - |
| 4905L | Unip | 7...18 | 5...16 | - |
| 4906L | Unip | 6,5...13,5 | 5...12 | - |
| 4913 | Omnip | 2...5/-5...-2 | 1,2...4,2/-4,2...-1,2 | - |
| 4935G-PB | Bip | 10...20 | -20...-10 | - |
| 4935L | Bip | 10...20 | -20...-10 | - |
| 4945L | Bip | -6...10 | -10...6 | - |
| 4946H | Bip | 11...17 | -17...-11 | - |
| 4946-1L | Bip | 11...19 | -19...-11 | - |
| 4966H | Bip | 5...10 | -10...-5 | - |
| 4966L | Bip | 5...10 | -10...-5 | - |
| 4976-1H | Unip | 5,5...11 | 5...10,5 | - |
| 4976L | Unip | 1...6 | 3...8 | - |
| Pol = Polarity, Bop = Turn-On Induction, BRP = Turn-Off Induction, DB = Differential Induction | ||||
 | ||||
| Note |
| The products with suffix -PB in this product group do not meet the requirements of the EU directive concerning the use of hazardous substances in electrical and electronic devices (RoHS). The use of these products may contradict hazardous-substance legislation in your country. Please refer to your country's relevant laws for RoHS and WEEE. |
|
| Terms of Delivery |
| Minimum order quantity: please see price list column "MOQ". Articles in bold print in stock, other articles available on request. |
|
| Manufacturer |
| Infineon http://www.infineon.com |
|
Stregkode:
81877
Intern reference:
81877
Varekode:
TLE4935L
