Super Fast Diode 200V 6A DO201AD

Varenummer:

78-373

Varekode:

SF64

Vægt:

0 g

Lagerstatus:

Ikke på lager

v/10

Kr. 6,47

v/25

Kr. 5,17

v/100

Kr. 3,89

v/1000

Kr. 2,59

Denne kombination eksistere ikke.

Køb

Technical Specifications

• The plastic conforms to UL94V-0
• Axial leads solderable per MIL-STD-202, Meth. 208
• Max. solderability 250°C/10s


Part Nr.	U_RRM	U_F	I_F(AV)	I_FSM	I_R	t_rr
	[V]	[V]	[A]	[A]	[μA]	[ns]
SF64	200	0,975	6,0	150	5,0	35
U_RRM = Max. Peak Recurrent Reverse Voltage, U_F = Max. Forward Voltage, I_F(AV) = Max. Average Forward Current, I_FSM = Peak Forward Surge Current, I_R = Max. Reverse Current, t_rr = Max. Reverse Recovery Time

Manufacturer

http://www.taiwansemi.com

Stregkode: 78373
Intern reference: 78373
Varekode: SF64
