600V 60A 200W TO247AD

Varenummer:

78-225

Varekode:

IXGH32N60CD1

Vægt:

0 g

Lagerstatus:

Ikke på lager

Denne kombination eksistere ikke.

Køb

Technical Specifications


Part Nr.	U_CES	I_C25	I_Cpuls	P_tot	U_GE(th)	t_d(on)	t_d(off)
IX_H_	[V]	[A]	[A]	[W]	[V]	[ns]	[ns]
20N120D1	1200	38	50	200	4,5	100	500
30N120D1	1200	60	76	300	4,5	100	500
12N60CD1	600	24	48	100	2,5	20	60
17N100AU1	1000	34	68	150	2,5	100	500
20N60BD1	600	40	80	150	2,5	15	110
20N120BD1	1200	40	100	190	2,5	25	150
32N60CD1	600	60	120	200	2,5	25	85
36N60B3D1	600	36	200	250	3,0	19	125
39N60BD1	600	76	152	200	2,5	25	250
24N60AU1	600	48	96	150	3,5	100	450
U_CES = Max. Collector-Emitter Breakdown Voltage, I_C25 = Max. Continuous Collector Current At T_C = 25°C, I_Cpuls = Max. Pulsed Collector Current, P_tot = Power Dissipation, U_GE(th) = Min. Gate Threshold Voltage, t_d(on) = Turn-On Delay Time, t_d(off) = Turn-Off Delay Time, T_C = Case Temperature

Additional Products

We will also deliver on request all other articles from IXYS, forward orders possible.

Manufacturer

http://www.ixys.com
