600V 14A 49W TO220AB

Varenummer:

78-168

Varekode:

IRG4BC15UDPBF

Vægt:

0 g

Lagerstatus:

Ikke på lager

v/10

Kr. 19,69

v/25

Kr. 13,12

v/100

Kr. 11,16

Denne kombination eksistere ikke.

Køb

Technical Specifications


Part Nr.	U_CES	I_C25	I_Cpuls	P_tot	U_GE(th)	t_d(on)	t_d(off)
IRG4B/B4_	[V]	[A]	[A]	[W]	[V]	[ns]	[ns]
C10KDPBF	600	9	18	38	3,0	49	97
C10UDPBF	600	8,5	34	38	3,0	40	87
C15UDPBF	600	14	42	49	3,0	17	160
C20FDPBF	600	16	64	60	3,0	43	240
C20KDPBF	600	16	32	60	3,0	54	180
C20SDPBF	600	19	38	60	3,0	62	690
C20UDPBF	600	13	52	60	3,0	39	93
C30FDPBF	600	31	120	100	3,0	42	230
C30KDPBF	600	28	58	100	3,0	60	160
C30UDPBF	600	23	92	100	3,0	40	91
045DPBF	600	12	20	77	4,0	27	75
056DPBF	600	24	48	140	4,0	31	83
059DPBF	600	8	16	56	4,0	25	65
060DPBF	600	16	32	99	4,0	30	95
061DPBF	600	36	72	206	4,0	40	105
062DPBF	600	48	96	250	4,0	41	104
064DPBF	600	20	40	101	4,0	27	79
U_CES = Max. Collector-Emitter Breakdown Voltage, I_C25 = Max. Continuous Collector Current At T_C = 25°C, I_Cpuls = Max. Pulsed Collector Current, P_tot = Power Dissipation, U_GE(th) = Min. Gate Threshold Voltage, t_d(on) = Turn-On Delay Time, t_d(off) = Turn-Off Delay Time, T_C = Case Temperature

Manufacturer

http://www.irf.com

Stregkode: 78168
Intern reference: 78168
Varekode: IRG4BC15UDPBF
