Relay SPDT 10A 9V 200R
Varenummer:
153-059
Varekode:
G5LE-1 9DC
Vægt:
10 g
Lagerstatus:
Ikke på lager
| Features |
| Sensitive coil: 400mV 2kV Coil/Contact Flux protected enclosure Withstands impulse of up to 4500V |
 |
| Technical
Specifications |
|
|
| Contact: | SPDT (Circular Contact) |
| Contact Material: | AgSnO2 |
| Rated Current: | 10A |
| Max. Switching Current: | 10A |
| Max. Switching Voltage: | 250V AC |
| Max. Switching Power: | 1200VA |
| Creepage/Clearance: | 3,3/2,7mm |
| Operate/Release Time: | 10/5ms |
| Testing Voltage | |
| Coil/Contact: | 2000V |
| Contact/Contact: | 750V |
| Lifetime | |
| Mechanical: | 10x106 Operations |
| Electrical: | 10x104 Operations |
| Operating Temperature: | -40...+85C |
| Weight Approx.: | 12g |
|
|
| Coil Data |
| Part Nr. | UN | Umax. | UAn | UAb | IN | PN | RN |
| [V DC] | [V] | [V] | [V] | [mA] | [mW] | [Ohm] | |
| G5LE-5 | 5 | 6,5 | 3,75 | 0,5 | 79,4 | 400 | 63 |
| G5LE-9 | 9 | 11,7 | 6,75 | 0,9 | 45,0 | 400 | 200 |
| G5LE-12 | 12 | 15,6 | 9 | 1,2 | 33,3 | 400 | 360 |
| G5LE-24 | 24 | 31,2 | 18 | 2,4 | 16,7 | 400 | 1440 |
| G5LE-48 | 48 | 62,4 | 36 | 4,8 | 8,3 | 400 | 5760 |
| UN = Rated Voltage, Umax. = Maximum Operating Voltage, UAn = Operate Voltage, UAb = Release Voltage, IN = Rated Current, PN = Rated Power, RN = Coil Resistance; All Specifications Measured at 23C | |||||||
|
|||||||
| Norms |
| Conforms to EN61810-1, UL508, CSA22.2 |
|
| Approvals |
    |
