8-Polet (2x4) konnektor DINKLE RM3,5
Varenummer:
151-424
Varekode:
159-03-S1473808
Vægt:
0 g
Lagerstatus:
Lager: 400 stk.
-
- Short description
- PCB Connector – Plug, Push-in Design
- Long description
- PCB Connector – Plug, Push-in Design, Pitch:3.50mm, 300V, 8A
- Category
- PCB Connector – Plug
- Pitch (mm)
- 3.5
- Color
- Black (default)
- Connection method
- Push in Design
- Type of locking
- Without
- Length (mm)
- 3.50*(P/2-1)+4.2
- Width (mm)
- 22.55
- Height (mm)
- 13.25
- Number of positions
- 04P~40P
- Level
- Double level
-
Material information
- Insulation material
- PA
- Insulation material group
- I
- Flame retardant rating , compliant with UL94
- V0
- Insulation resistance
- ≥500MΩ at DC 500V
- Conductor material
- COPPER ALLOY
- Plating of conductor surface
- Tin PLATED
-
Connection data-IEC
- Rated voltage (V)
- 250
- Rated current (A)
- 8
- Rated voltage (II/2)(V)
- 320
- Rated voltage (III/2) (V)
- 160
- Rated voltage (III/3)(V)
- 160
- Rated impulse voltage (II/2)(KV)
- 2.5
- Rated impulse voltage (III/2)(KV)
- 2.5
- Rated impulse voltage (III/3)(KV)
- 2.5
- Conductor cross section solid. min (mm²)
- 0.2
- Conductor cross section solid.max (mm²)
- 1.5
- Conductor cross section stranded. min (mm²)
- 0.2
- Conductor cross section stranded. max (mm²)
- 1.5
- Conductor cross section flexible, with min ferrule without plastic sleeve (mm²)
- 0.25
- Conductor cross section flexible, with max ferrule without plastic sleeve (mm²)
- 1.5
- Conductor cross section flexible, with min ferrule with plastic sleeve (mm²)
- 0.25
- Conductor cross section flexible, with max ferrule with plastic sleeve (mm²)
- 0.75
- Stripping Length (mm)
- 9~10
-
Connection data-UL
- Rated voltage (UL/CUL Group B)(V)
- 300
- Rated current (UL/CUL Group B)(A)
- 8
- Min. solid wire connection (AWG) acc. to UL/CUL
- 24
- Max. solid wire connection AWG acc. to UL/CUL
- 16
- Min. stranded wire connection AWG acc. to UL/CUL
- 24
- Max. stranded wire connection AWG acc. to UL/CUL
- 16
-
Environment & Safety
- Finger protection (YES or NO)
- YES
- Operating temperature. max (°C)
- 120
- Operating temperature. min (°C)
- -40
-
UL Recognized
- Wire Range (Group B)(AWG)
- 24~16
- Rated voltage (Group B)(V)
- 300
- Rated current (Group B)(A)
- 8
- Wire Range (Group C)(AWG)
- 24~16
- Rated voltage (Group C)(V)
- 50
- Rated current (Group C)(A)
- 8
- Wire Range (Group D)(AWG)
- 24~16
- Rated voltage (Group D)(V)
- 300
- Rated current (Group D)(A)
- 8
-
CUL Recognized
- Wire Range (Group B)(AWG)
- 24~16
- Rated voltage (Group B)(V)
- 300
- Rated current (Group B)(A)
- 8
- Wire Range (Group C)(AWG)
- 24~16
- Rated voltage (Group C)(V)
- 50
- Rated current (Group C)(A)
- 8
- Wire Ranget (Group D)(AWG)
- 24~16
- Rated voltage (Group D)(V)
- 300
- Rated current (Group D)(A)
- 8
Stregkode:
151424
Intern reference:
151424
Varekode:
159-03-S1473808
