  6. MKT Capacitor 22nF 100V 10% P5 R82

MKT Capacitor 22nF 100V 10% P5 R82

Varenummer:
151-105
Varekode:
C82NF022L
Vægt:
0 g
Lagerstatus:
Ikke på lager

kr 0,00 0.0 DKK kr 0,00 Inklusiv moms

kr 0,00 Inklusiv moms

Anmod os om en pris

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/125626/image_1920?unique=14ab7d4 https://elektroniklavpris.odoo.com/web/image/product.template/125626/image_1920?unique=14ab7d4

Features

• Dielectric, polyester film (polyethylene terephthalate)
• Box material is solvent resistant and flame retardant according to UL94V-0
• Tinned wire leads
• Low attenuation
• High pulse rating
Technical Specifications

Rated Voltage (UN): See Table
Test Voltage (2s; 25±5°C): 1,4xUN
Capacitance Tolerance (1kHz): ±10%
Temperature Range: -55...+105°C
Climatic Category
IEC 60068-1: 55/100/56
Insulation Resistance, Min.
to incl. 330nF: 15GOhm
330nF...1µF: 5000s
from 1µF: 1000s
Pulse Rise Time, Max. (du/dt)
100V DC: 100V/µs
63V DC: 70V/µs
Reliability (MIL HDB 217) (40°C, 0,5 x UN): 1,0fit1)
1) 1fit = 1x10 -9 Failure Components/Hour

Part Nr. CN UN Ueff B H Ød
  [nF] [V DC] [V AC] [mm] [mm] [mm]
C82NF001.0L 1,0 100 63 2,5 6,5 0,5
C82NF002.2L 2,2 100 63 2,5 6,5 0,5
C82NF003.3L 3,3 100 63 2,5 6,5 0,5
C82NF004.7L 4,7 100 63 2,5 6,5 0,5
C82NF006.8L 6,8 100 63 2,5 6,5 0,5
C82NF010L 10 100 63 2,5 6,5 0,5
C82NF022L 22 100 63 2,5 6,5 0,5
C82NF047L 47 100 63 2,5 6,5 0,5
C82NF068L 68 100 63 2,5 6,5 0,5
C82NF100L 100 63 40 2,5 6,5 0,5
C82NF150L 150 63 40 2,5 6,5 0,5
C82NF220L 220 63 40 2,5 6,5 0,5
C82NF330L 330 63 40 3,5 7,5 0,5...0,6
C82NF470L 470 63 40 3,5 7,5 0,5...0,6
C82NF680L 680 63 40 5,0 10,0 0,5...0,6
C82UF001L 1000 63 40 5,0 10,0 0,5...0,6
CN = Rated Capacitance, UN = Rated Voltage DC, Ueff = RMS Voltage
