Environmental conditions
Temperature range:-40 °C/+120 °C *1
1) upper limit temperature (insulating body) RTI (electrical) of the UL Yellow Card
Materials
Insulating body:PA GF, V-0 according to UL94 *1
Contact pin:CuZn, pre-nickel and tin-plated
1) component glow wire resistant (GWT 750 °C), testing acc. to IEC 60695-2-11, assessment acc. to IEC 60335-1 (flame
Electrical data (at Tamb 20 °C)
Rated current:4 A (Tamb 80 °C, VDE)
2 A (Tamb 120 °C, VDE/cULus)
Rated voltage:160 V AC
32 V AC (VDE)
250 V AC (cULus)
