MKP Capacitor 1,5uF X2 275V P27,5

Varenummer:
148-154
Varekode:
C46UF001,5
Vægt:
0 g
Lagerstatus:
Ikke på lager

kr 10,32 10.32 DKK kr 10,32 Inklusiv moms

kr 10,32 Inklusiv moms

Anmod os om en pris

v/10
Kr. 10,14
v/25
Kr. 8,29
v/100
Kr. 5,53
v/1000
Kr. 4,56

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/122678/image_1920?unique=14ab7d4 https://elektroniklavpris.odoo.com/web/image/product.template/122678/image_1920?unique=14ab7d4

Gruppe: C5813
KEMET/ARCOTRONICS MKP Metallized Film Capacitors
Series: R.46
Wound Technology, Class X2
Style: Bulk
Rated Voltage: 275/300V AC
Tolerance: 20%
Pitch: 15...37,5mm

Features

• Dielectric polypropylene film. Aluminium layer plates deposited by evaporation under vacuum
• Box material is solvent resistant and flame retardant (UL94V-0), no impregnation
• Low attenuation
• Low dissipation factor (tan d)
• High pulse strength (du/dt)
• High insulation resistance
Technical Specifications

Rated Voltage (50/60Hz): 275V AC
C463NF470: 300V AC
Capacitance Tolerance: ±20%
Temperature Range: -40...+110°C
Climatic Category (IEC60068-1): 40/100/56
Insulation Resistance, Min.
to incl. 330nF: 1x105MOhm
from 330nF: 30000s
Dissipation Factor Tan d (1kHz, ±25°C), Max.: 10x10-4

Part Nr. CN du/dt B H L P Ø
  [nF] [V/µS] [mm] [mm] [mm] [mm] [mm]
C46NF010 10 400 5 11 18 15 0,6
C46NF015 15 400 5 11 18 15 0,6
C46NF022 22 400 5 11 18 15 0,6
C46NF033 33 400 5 11 18 15 0,6
C46NF047 47 400 5 11 18 15 0,6
C46NF068 68 400 5 11 18 15 0,6
C46NF100 100 400 6 12 18 15 0,6
C46NF150-15M2M 150 400 6 12 18 15 0,6
C46NF150-22 150 200 6 15 26,5 22,5 0,8
C46NF220 220 200 6 15 26,5 22,5 0,8
C46NF330 330 200 7 16 26,5 22,5 0,8
C46NF470 470 200 10 18,5 26,5 22,5 0,8
C463NF470 470 200 7 16 26,5 22,5 0,8
C46NF680 680 150 10 20 32,0 27,5 0,8
C46UF001 1000 150 11 20 32,0 27,5 0,8
C46UF002.2P0M 2200 150 13,0 22,0 32,0 27,5 0,8
C46UF003.3 3300 150 18,0 33,0 32,0 27,5 0,8
C46UF004.7 4700 150 22,0 37,0 32,0 27,5 0,8
C46UF0010 10000 100 30 45 41,5 37,5 1,0
CN = Rated Capacitance, du/dt = Pulse Strength, Max. at 390V DC
Labelling
Manufacturer logo, series, rated capacitance, tolerance, rated voltage, class, climatic category, manufacturing date code, approvals
Approvals
According to EN132400 (CCEE IEC60384-14 / 2:1993 and A1:1995; IEC60065)
CSA and UL 1414 up to 1µA; UL 1283 for 310V AC
03
Kontakt os

Stregkode: 148154
Intern reference: 148154
Varekode: C46UF001,5
