  6. MKT Capacitor 1,5nF 63V 10% P5,08

MKT Capacitor 1,5nF 63V 10% P5,08

Varenummer:
147-152
Varekode:
IRD001,5NF
Vægt:
0 g
Lagerstatus:
Ikke på lager

kr 1,00 1.0 DKK kr 1,00 Inklusiv moms

kr 1,00 Inklusiv moms

Anmod os om en pris

v/10
Kr. 1,00
v/25
Kr. 0,88
v/100
Kr. 0,62

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/121676/image_1920?unique=14ab7d4 https://elektroniklavpris.odoo.com/web/image/product.template/121676/image_1920?unique=14ab7d4

Features

• Metallized polyester film
• High pulse rating
• Self-healing properties
• Low inductance
Technical Specifications

Rated Voltage (UN): See Table
Test Voltage (2s, 25°C): 1,6xUN
Capacitance Tolerance: ±10%
Temperature Range: -55...+100°C
Climatic Category 55/100/56
Tangent of Loss Angle d
(1kHz, 1000h): �80x10-4
Insulation Resistance
CN�30nF: 15GW
CN>30nF: Ri xCN³5000s
Pulse Rise Time, Max. (du/dt)
63V: 150V/μs
100V: 200V/μs

Part Nr. CN UN L H e
  [nF] [V=] [mm] [mm] [mm]
IRD001NF 1 100 7,5 6,5 2,5
IRD002,2NF 2,2 100 7,5 6,5 2,5
IRD003,3NF 3,3 100 7,5 6,5 2,5
IRD004,7NF 4,7 100 7,5 6,5 2,5
IRD006,8NF 6,8 100 7,5 6,5 2,5
IRD010NF 10 100 7,5 6,5 2,5
IRD022NF 22 100 7,5 6,5 2,5
IRD033NF 33 63 7,5 6,5 2,5
IRD047NF 47 63 7,5 6,5 2,5
IRD068NF 68 63 7,5 6,5 2,5
IRD100NF 100 63 7,5 6,5 2,5
IRD150NF 150 63 7,5 8,0 3,2
IRD220NF 220 63 7,5 8,0 3,2
IRD470NF 470 63 7,5 8,0 5,0
IRD680NF 680 63 7,5 9,6 6,0
IRD001UF 1000 63 7,5 8,0 5,0
CN = Rated Capacitance, UN = Rated Voltage DC
Norms
CET384-1, CECC30000, UTE83100
Sectional specifications: CET384-2, CECC30400, UTE83151
Labelling
Thomson logo, rated capacitance, tolerance (according to EIA-Code), rated voltage (V DC)
Manufacturer
AVX
http://www.avx.comFeatures
• Metallized polyester film
• High pulse rating
• Self-healing properties
• Low inductance
Technical Specifications

Rated Voltage (UN): See Table
Test Voltage (2s, 25°C): 1,6xUN
Capacitance Tolerance: ±10%
Temperature Range: -55...+100°C
Climatic Category 55/100/56
Tangent of Loss Angle d
(1kHz, 1000h): �80x10-4
Insulation Resistance
CN�30nF: 15GW
CN>30nF: Ri xCN³5000s
Pulse Rise Time, Max. (du/dt)
63V: 150V/μs
100V: 200V/μs

Part Nr. CN UN L H e
  [nF] [V=] [mm] [mm] [mm]
IRD001NF 1 100 7,5 6,5 2,5
IRD002,2NF 2,2 100 7,5 6,5 2,5
IRD003,3NF 3,3 100 7,5 6,5 2,5
IRD004,7NF 4,7 100 7,5 6,5 2,5
IRD006,8NF 6,8 100 7,5 6,5 2,5
IRD010NF 10 100 7,5 6,5 2,5
IRD022NF 22 100 7,5 6,5 2,5
IRD033NF 33 63 7,5 6,5 2,5
IRD047NF 47 63 7,5 6,5 2,5
IRD068NF 68 63 7,5 6,5 2,5
IRD100NF 100 63 7,5 6,5 2,5
IRD150NF 150 63 7,5 8,0 3,2
IRD220NF 220 63 7,5 8,0 3,2
IRD470NF 470 63 7,5 8,0 5,0
IRD680NF 680 63 7,5 9,6 6,0
IRD001UF 1000 63 7,5 8,0 5,0
CN = Rated Capacitance, UN = Rated Voltage DC
Norms
CET384-1, CECC30000, UTE83100
Sectional specifications: CET384-2, CECC30400, UTE83151
Labelling
Thomson logo, rated capacitance, tolerance (according to EIA-Code), rated voltage (V DC)
Manufacturer
AVX
http://www.avx.com
