Relay SPDT 12V 6A 848R

Varenummer:
144-402
Varekode:
AZ6991-1CE-12DEA
Vægt:
10 g
Lagerstatus:
Ikke på lager

kr 36,00 36.0 DKK kr 36,00 Inklusiv moms

kr 36,00 Inklusiv moms

Anmod os om en pris

v/10
Kr. 32,50
v/50
Kr. 27,50
v/100
Kr. 22,50

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/106681/image_1920?unique=864978b https://elektroniklavpris.odoo.com/web/image/product.template/106681/image_1920?unique=864978b
Features
• Sensitive Subminiatur Relais
• Extremely small height (5mm)
• 8A switching capability
• Dielectric strength 4000Vrms contact to coil
• Isolation soacing greater than 8mm
• Reinforced insulation
Technical Specifications

Contact:
AZ6991-1A_: SPST
AZ6991-1C_: SPDT
Contact Material: AgNi
AZ6991-1CE_: AgSnO2
AZ6991-1CE-_A: Gold plating
Rated Current: 6A
Max. Switching Current: 8A
Max. Switching Voltage: 400V AC / 125V DC
Max. Switching Power: 2216VA /180W
Operate/Release Time: 8/4ms
Testing Voltage (FCC)
Coil/Contact: 4000VRMS
Open Contacs: 1000VRMS
Lifetime
Mechanical, Min.: 1x107 Operations
Electrical, Min. (5A / 250V AC): 1x105 Operations
Operating Temperature: -40...+85°C
Max. Solder Temperature: 260°C (5s)
Weight Approx.: 5g
Coil Data

Part Nr. UN Umin. Umax. PN RN
  [V DC] [V DC] [V DC] [mW] [Ohm]
AZ6991-1A-12DE 12 9,0 18 170 848
AZ6991-1A-24DE 24 18,0 36 170 3390
AZ6991-1C-5DE 5 3,75 7,5 170 147
AZ6991-1C-12DE 12 9,0 18 170 848
AZ6991-1C-24DE 24 18,0 36 170 3390
AZ6991-1CE-12DEA 12 9,0 18 170 848
AZ6991-1CE-24DEA 24 18,0 36 170 3390
AZ6991-1CE-12DE 12 9,0 18 170 848
AZ6991-1CE-24DE 24 18,0 36 170 3390
UN = Rated Voltage, UMin. = Maximum Operating Voltage, UMax. = Maximum Operating Voltage, PN = Rated Power, RN = Coil Resistance; Rated Value ±10%; All Specifications Measured at 20°C
Approvals
 (File No. E43203)
 (File No. 40020561)
Additional Products
Also available on request:Relays with 6V to 60V DC rated voltages.
