Minijack 4-pol - 3 x phono kabel 1,5m
Brand:
3x phono plug - 3.5mm jack plug (3-rings), 1.50m
Pin-out (counted from tip to bottom)
Tip - Left/Venstre audio HVID
2e ring - Video/billede GULD
3e ring - Ground / stel
4e ring - Right/Højre audio RØD
| Brand | Valueline |
| Usage | Video |
| Connector 1 | 3x RCA Male |
| Connector 2 | Jack AV Male 3.5mm |
| Gold Plated | No |
| Length | 1,5 m |
| Connector Type | Angled + Straight |
| Colour | Black |
3.5mm 4 Pole Straight Jack to 3 Phono Cable
A four pole straight 3.5mm jack plug to 3 phono plugs cable suitable for connecting a digital camcorder or portable DVD player to A/V equipment or a computer. The three phono plugs are colour coded for composite video (yellow) and stereo audio (red and white). This cable is 1,5m long and the 3.5mm 4 pole jack has the standard Sony type wiring configuration (tip audio L / Video / Ground / Audio R).
Billigt alternativ til SONY 1-848-803-13 (dog med han-stik, i stedet for adapterens hunstik - brug evt. adapteren under relaterede produkter)
