Serie 719 Male Socket 8-Pole Solder Term.
Varenummer:
126-817
Varekode:
BIN09-0173-00-08
Vægt:
10 g
Lagerstatus:
Ikke på lager
Gruppe: F4228
BINDER Subminiature Connectors
Series: M16, 719
Panel Mounting, IP67
| Features |
| • Panel mounting connectors with screw locking according to IEC60130-9 • Precision metal construction • excellent EMC shielding • Degree of protection IP67 |
 |
| Technical Specifications |
|
|||||||||||||||||||||||||||
| Connector Locking System: | Screw | Termination: | Solder | Wire Gauge, Max. | BIN09-_-0003, -0005, -0008: | 0,75mm2 | BIN09-_-0012: | 0,25mm2 | Degree of Protection: | IP67 | Mechanical Operating Life: | >500 Cycles | Temperature Range: | -30...+95°C | Rated Voltage: | see Table | Rated Current (40°C): | see Table | Contact Resistance, Max.: | see Table | Material of Contact: | CuZn | Material of Housing: | Zn (Diecasting), Nickel-plated | |||
|
|||||||||||||||||||||||||||
| Part-Nr. | Pole | UN | IN | R | Contact | BIN09-_ | [V] | [A] | [mW] | Plating | 0107-0003 | 3 | 250 (32) | 7 | 5 | Ag | 0115-0005 | 5 | 250 (32) | 6 | 5 | Ag | 0173-0008 | 8 | 60 (32) | 5 | 5 | Ag | 0131-0012 | 12 | 60 (32) | 3 | 3 | Au | 0108-0003 | 3 | 250 (32) | 7 | 5 | Ag | 0116-0005 | 5 | 250 (32) | 6 | 5 | Ag | 0174-0008 | 8 | 60 (32) | 5 | 5 | Ag | 0132-0012 | 12 | 60 (32) | 3 | 3 | Au | |||||||
| UN = Rated Voltage, IN = Rated Current (40°C), R = Contact Resistance, Max. | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
| Binder http://www.binder-connector.de |
|
Stregkode:
261-6130
Intern reference:
126817
Varekode:
BIN09-0173-00-08
