Ræle 3 x slutte + 1 x bryde 24VDC 6A 1152R
Varenummer:
126-494
Varekode:
SF3-DC24V
Vægt:
0 g
Lagerstatus:
Ikke på lager
- RELAY, FORCED CONTACT, 4PCO, 24VDC
- Coil Voltage VDC Nom: 24V
- Coil Resistance: 1.152kohm
- Contact Current Max: 6A
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Nom: 24V
- Contact Configuration: 4PST
- No. of Poles: 4
- Relay Mounting: Through Hole
- External Height: 53.3mm
- External Width: 33mm
- External Depth: 16.5mm
- SVHC: No SVHC (19-Dec-2012)
- Coil Operating Lower Percent Limit: 75%
- Coil Operating Upper Percent Limit: 120%
- Coil Type: DC Monostable
- Contact Current AC Max: 10A
- Contact Current DC Max: 10A
- Contact Voltage AC Max: 440V
- Contact Voltage DC Max: 24V
- Current Rating: 6A
- DC Coil Power: 500mW
- External Length / Height: 53.3mm
- Mounting Type: PCB
- Nom Operating Power: 500mW
- Operating Temperature Max: 70°C
- Operating Temperature Min: -40°C
- Power Consumption: 500mW
- Relay Type: General Purpose
- Series: SF3
- Supply Voltage: 24V
- Switch Current Max: 20A
- Switching Current Max: 20A
- Switching Frequency: 10 Hz (without load)
- Switching Voltage Max: 440V
Stregkode:
126494
Intern reference:
126494
Varekode:
SF3-DC24V
