FKP Capacitor 6,8nF 63V 10% P5

Varenummer:
115-931
Varekode:
FKP2N006,8K63-5
Vægt:
0 g
Lagerstatus:
Ikke på lager

kr 3,04 3.04 DKK kr 3,04 Inklusiv moms

kr 3,04 Inklusiv moms

Anmod os om en pris

v/10
Kr. 2,09
v/25
Kr. 1,71
v/100
Kr. 1,14
v/1000
Kr. 0,69

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/45957/image_1920?unique=c26168f https://elektroniklavpris.odoo.com/web/image/product.template/45957/image_1920?unique=c26168f
FKP2 6800pF
6800pF = 6,8nF



Features

• Dielectric: polyethylene-terephthalate (PET) film
• Vacuum-deposited capacitor electrodes
• Encapsulation: solvent-resistant, flame-retardent plastic case with epoxy resin seal, UL 94 V-0
• Terminations: tinned wire
• High volume/capacitance ratio and reduced base
• Self-healing
Typical Applications

For general DC-applications e.g. By-pass, Blocking, Coupling and decoupling, Timing
Technical Specifications

Rated Voltages (UN):
 see Table
Test Voltage (2s):
 1,6xUN
Capacitance tolerances:
 ±10%
Operating temperature range:
 -55...+100°C
Climatic test category IEC:
 55/100/21
Insulation resistance
C�330nF, 63V:
 ³1000MW
C�330nF, 100V:
 ³1500MW
C>330nF, 63V:
 ³1250s
C>330nF, 100V:
 ³3000s
Relliability (failure rate) (40°C, 0,5 x UN):
 2,0 fit1)
1) 1fit = 1x10 -9 Failure Components/Hour

Part Nr.
 CN
 UN
 Ueff
 B
 H
 L
 P
MKS2_
 [nF/μF]
 [V DC]
 [V AC]
 [mm]
 [mm]
 [mm]
 [mm]
N010K63-5 10
 63
 40
 2,5
 6,5
 7,2
 5,0
N015K63-5 15
 63
 40
 2,5
 6,5
 7,2
 5,0
N022K63-5 22
 63
 40
 2,5
 6,5
 7,2
 5,0
N033K63-5 33
 63
 40
 2,5
 6,5
 7,2
 5,0
N047K63-5 47
 63
 40
 2,5
 6,5
 7,2
 5,0
N068K63-5 68
 63
 40
 2,5
 6,5
 7,2
 5,0
N100K63-5 100
 63
 40
 2,5
 6,5
 7,2
 5,0
N150K63-5 150
 63
 40
 2,5
 6,5
 7,2
 5,0
N220K63-5 220
 63
 40
 2,5
 6,5
 7,2
 5,0
N330K63-5 330
 63
 40
 2,5
 6,5
 7,2
 5,0
N470K63-5 470
 63
 40
 2,5
 6,5
 7,2
 5,0
N680K63-5 680
 63
 40
 2,5
 6,5
 7,2
 5,0
U1,0K63-5 1,0
 63
 40
 2,5
 6,5
 7,2
 5,0
U1,5K63-5 1,5
 63
 40
 2,5
 6,5
 7,2
 5,0
U2,2K63-5 2,2
 63
 40
 2,5
 6,5
 7,2
 5,0
U3,3K63-5 3,2
 63
 40
 2,5
 6,5
 7,2
 5,0
N010K100-5 10
 100
 63
 2,5
 6,5
 7,2
 5,0
N015K100-5 15
 100
 63
 2,5
 6,5
 7,2
 5,0
N047K100-5 47
 100
 63
 2,5
 6,5
 7,2
 5,0
N068K100-5 68
 100
 63
 2,5
 6,5
 7,2
 5,0
N100K100-5 100
 100
 63
 2,5
 6,5
 7,2
 5,0
N150K100-5 150
 100
 63
 2,5
 6,5
 7,2
 5,0
N220K100-5 220
 100
 63
 2,5
 6,5
 7,2
 5,0
N330K100-5 330
 100
 63
 2,5
 6,5
 7,2
 5,0
N470K100-5 470
 100
 63
 2,5
 6,5
 7,2
 5,0
CN = Rated Capacitance, UN = Rated Voltage DC, Ueff = RMS Voltage
Pulse rise time

CN
 F63V
 F100V
  [V/μs]
 [V/μs]
10n...22nF:
 35/350
 35/350
33n...68nF:
 20/200
 25/250
100n...470nF:
 15/150
20/200
680n...1μF:
 12/120
15/150
1,5μ...3,3μF:
 7,5/75
 10/100
F63V = Pulse rise time for 63V, F100V = Pulse rise time for 100V
Dissipation Factor Tand (20°C)

    Measured at

  1kHz
 10kHz
 100kHz
C �8x10-3
 �15x10-3
 �30x10-3
100nF �8x10-3
 �15x10-3
 -
C �10x10-3
 -
 -

Labelling
Colour red, Marking: silver/white
Epoxy resin seal: colour yellow


Manufacturer

http://www.wima.de
