• Stable temperature and frequency characteristics
• Low leakage current, low dissipation factor
• High resistance to shock and vibration
• Flame retardant plastic case UL94V-0
|
 |
• Telecommunications, measuring and control engineering, automotive electronics, DC/DC converters
|
|
|
|
|
Technology:
|
Ta-MnO2
|
Rated Voltage:
|
See Table
|
Capacitance Tolerance:
|
±10%
|
Temperature Range:
|
-55...+85°C
|
With Voltage Reduction:
|
+85...+125°C
|
Climatic Category:
|
55/125/56
|
Service Life:
|
>500000h
|
|
|
|
|
|
|
|
|
|
Part Nr.
|
C
|
UN
|
U125
|
RESR
|
ILK
|
IAC
|
Chip
|
B45197A-_
|
|
|
|
|
|
|
Size
|
| |
[μF]
|
[V]
|
[V]
|
[mW]
|
[μA]
|
[A]
|
|
| 100D |
100
|
10
|
6,3
|
100
|
10
|
1,22
|
D
|
| 220E |
220
|
10
|
6,3
|
100
|
22
|
1,28
|
E
|
| 330E |
330
|
10
|
6,3
|
100
|
33
|
1,28
|
E
|
| 033D |
33
|
16
|
10
|
200
|
5,3
|
0,87
|
D
|
| 047D |
47
|
16
|
10
|
175
|
7,5
|
0,93
|
D
|
| 100E |
100
|
16
|
10
|
100
|
16
|
1,28
|
E
|
| 068E |
68
|
20
|
13
|
200
|
14
|
0,91
|
E
|
| 004,7C |
4,7
|
25
|
16
|
525
|
1,2
|
0,46
|
C
|
| 022D |
22
|
25
|
16
|
230
|
5,5
|
0,81
|
D
|
| 010D |
10
|
35
|
23
|
260
|
3,5
|
0,76
|
D
|
| 022E |
22
|
35
|
23
|
260
|
7,7
|
0,80
|
E
|
C = Capacitance, UN = Rated Voltage DC 35 to +85°C, U125 = Decreased Rated Voltage DC to 125°C, RESR = Equivalent Series Resistance (20°C, 100 kHz), ILK=Leakage Current (20°C, UN, 5Min), IAC = Alternating Current (20°C, 100kHz)
|
|
|
|
|
|
|
|
|
|
Chip
|
L±0,3
|
W±0,3
|
H±0,3
|
L2typ.
|
W2±0,1
|
H2typ.
|
P±0,3
|
| |
|
|
|
[mm]
|
|
|
|
C
|
6,0
|
3,2
|
2,5
|
5,8
|
2,2
|
1,5
|
1,3
|
| D |
7,3
|
4,3
|
2,8
|
7,1
|
2,4
|
1,6
|
1,3
|
| E |
7,3
|
4,3
|
4,1
|
7,1
|
2,4
|
1,6
|
1,3
|
|
| Labelling |
Manufacturer, polarity bar (positive pole marking), capacitance, date code, rated voltage
|
|
|
