FKP Capacitor 1,8nF 2000V 10% P22,5

Varenummer:
110-909
Varekode:
PHE431SD4180K
Vægt:
0 g
Lagerstatus:
Ikke på lager

kr 14,06 14.06 DKK kr 14,06 Inklusiv moms

kr 14,06 Inklusiv moms

Anmod os om en pris

v/10
Kr. 12,30
v/25
Kr. 8,79
v/100
Kr. 5,27

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/39616/image_1920?unique=c26168f https://elektroniklavpris.odoo.com/web/image/product.template/39616/image_1920?unique=c26168f
Fabrikat: RIFA
Features
• Dielectric: Polypropylene film
• Capacitor electrodes: Double-sided metallized plastic film
• Encapsulation: solvent-resistant, flame-retardent plastic case with epoxy resin seal, UL94V-0
• Terminations: tinned wire
• Pulse duty construction
• Self-healing
• Very low dissipation factor
• Negative capacitance change versus temperature
Typical Applications
For pulse applications e.g. switch mode power supplies, TV and monitor sets, lighting, audio/video equipment
Technical Specifications
Rated Voltages (UN):
 see Table
Test Voltage (2s):
 1,6xUN
Capacitance Tolerances:
 ±10%
Operating Temperature Range:
 -55...+100°C
Climatic Test Category IEC:
 55/100/56
Insulation Resistance
C�330nF:
 ³100000 MW
C>330nF:
 ³30000s
Failure Rate (40°C, 0,5 x UN):
 1,0 fit1)
1) 1fit = 1x10 -9 Failure Components/Hour
Part Nr.
 CN
 UN
 Ueff
 B
 H
 L
 RM
FKP1_
 [nF]
 [V DC]
 [V AC]
 [mm]
 [mm]
 [mm]
 [mm]
P100K2000-15 0,1
 2000
 700
 5,0
 11,0
 18,0
 15,0
P150K2000-15 0,15
 2000
 700
 5,0
 11,0
 18,0
 15,0
P220K2000-15 0,22
 2000
 700
 5,0
 11,0
 18,0
 15,0
P330K2000-15 0,33
 2000
 700
 6,0
 12,5
 18,0
 15,0
P470K2000-15 0,47
 2000
 700
 6,0
 12,5
 18,0
 15,0
P680K2000-15 0,68
 2000
 700
 6,0
 12,5
 18,0
 15,0
N1,0K1250-15 1,0
 1250
 600
 5,0
 11,0
 18,0
 15,0
N1,0K1600-15 1,0
 1600
 650
 6,0
 12,5
 18,0
 15,0
N1,0K2000-15 1,0
 2000
 700
 7,0
 14,0
 18,0
 15,0
N1,5K1250-15 1,5
 1250
 600
 5,0
 11,0
 18,0
 15,0
N1,5K1600-15 1,5
 1600
 650
 7,0
 14,0
 18,0
 15,0
N1,5K2000-22 1,5
 2000
 700
 6,0
 15,0
 26,5
 22,5
N2,2K1250-15 2,2
 1250
 600
 5,0
 11,0
 18,0
 15,0
N2,2K1600-15 2,2
 1600
 650
 8,0
 15,0
 18,0
 15,0
N2,2K2000-22 2,5
 2000
 700
 7,0
 16,5
 26,5
 22,5
N3,3K1250-15 3,3
 1250
 600
 6,0
 12,5
 18,0
 15,0
N3,3K1600-22 3,3
 1600
 650
 6,0
 15,0
 26,5
 22,5
N3,3K2000-22 3,3
 2000
 700
 7,0
 16,5
 26,5
 22,5
N4,7K1250-15 4,7
 1250
 600
 7,0
 14,0
 18,0
 15,0
N4,7K1600-22 4,7
 1600
 650
 7,0
 16,5
 26,5
 22,5
N4,7K2000-22 4,7
 2000
 700
 8,5
 18,5
 26,5
 22,5
N6,8K1600-22 6,8
 1600
 650
 8,5
 18,5
 26,5
 22,5
N6,8K2000-22 6,8
 2000
 700
 10,5
 20,5
 26,5
 22,5
N010K1600-22 10
 1600
 650
 10,5
 20,5
 26,5
 22,5
N010K2000-27 10
 2000
 700
 11,0
 21,0
 31,5
 27,5
N015K2000-27 15
 2000
 700
 13,0
 24,0
 31,5
 27,5
N022K2000-27 22
 2000
 700
 15,0
 26,0
 31,5
 27,5
N033K2000-37 33
 2000
 700
 13,0
 24,0
 41,5
 37,5
N047K2000-37 47
 2000
 700
 17,0
 29,0
 41,5
 37,5
N068K1000-27 68
 1000
 600
 13,0
 24,0
 31,5
 27,5
N068K2000-37 68
 2000
 700
 19,0
 32,0
 41,5
 37,5
N100K1250-37 100
 1250
 600
 15,00
 26,0
 41,5
 37,5
N150K1250-37 150
 1250
 600
 17,0
 29,0
 41,5
 37,5
N220K1250-37 220
 1250
 600
 19,0
 32,0
 41,5
 37,5
CN = Rated Capacitance, UN = Rated Voltage DC, Ueff = RMS Voltage
Pulse Rise Time
CN
 F1000V
 F1250V
 F1600V
 F2000V
  [V/μs]
 [V/μs]
 [V/μs]
 [V/μs]
0,1nF...0,22nF -
 -
 56000
 56000
0,33nF...0,68nF -
 -
 51000
 56000
1,0nF...2,2nF: 29000
 29000
 46000
 51000
3,3nF...6,8nF: 27000
 29000
 29000
 29000
10nF...22nF: 11000
 11000
 11000
 13000
33nF...68nF 11000
 11000
 11000
 11000
100F...220nF: 11000
 11000
 11000
 -
F1000V...2000V = Pulse rise time for 1000...2000V
Dissipation Factor Tand (20°C)
    Measured at

  1kHz
 10kHz
 100kHz
C �3x10-4
 �4x10-4
 �10x10-4
100nF �3x10-4
 �6x10-4
 -
Labelling
Colour red, Marking: black
Epoxy resin seal: colour yellow
Manufacturer

http://www.wima.de
