Relay SPDT 6V 10A 75R Horizontal

Varenummer:
110-870
Varekode:
F4011-6A
Vægt:
40 g
Lagerstatus:
Lager: 11 stk.

kr 38,70 38.7 DKK kr 38,70 Inklusiv moms

kr 38,70 Inklusiv moms

Anmod os om en pris

v/10
Kr. 36,29
v/25
Kr. 30,24
v/100
Kr. 24,19
v/1000
Kr. 18,14

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/39578/image_1920?unique=864978b https://elektroniklavpris.odoo.com/web/image/product.template/39578/image_1920?unique=864978b
Features
• Horizontal type
• Relay protection class RTI
Technical Specifications
Insulation According to EN61810-5:
 4kV/3
Insulation Voltage 1,2/50μs
Contact/Coil:
 6kV
Open Contacts:
 1kV
Clearance and Creepage:
 8mm
Temperature Range:
 -40...+70°C
Operate Time, Typ.:
 12ms
Release Time, Typ.:
 4ms
Contact Data
Contact Confirguration:
 SPDT
Contact Material:
 AgCdO
Rated/ Switching Voltage (Ohmic Load), Max.
AC 1/230V:
 2500VA
AC 15/230V:
 500VA
Rated/Switching Voltage AC:
 250/400V AC
Rated Current, Max.:
 10A
Peak Current, Max.:
 20A
Operating Life
Mechanical:
 20x106 Operations
Electrical:
 200x103 Operations
Coil Data
Part Nr.
 UN
 UAn
 Umax.
 IN
 RN
  [V DC]
 [V DC]
 [V DC]
 [mA]
 [W]
F4011-6A 6
 5
 9
 80
 75
UN = Rated Voltage, UAn = Operate Voltage, Umax. = Maximum Voltage, IN = Rated Current, RN = Coil Resistance, All Technical Specifications are Valid for 20°C
Manufacturer

http://www.finder.de
Kontakt os

Stregkode: 110870
Intern reference: 110870
Varekode: F4011-6A
