Dig. Isol. 4Ch 5kV 90MBd SOL16

Varenummer:

108-806

Varekode:

ADUM2400CRWZ

Vægt:

0 g

Lagerstatus:

Ikke på lager

v/10

Kr. 94,69

v/47

Kr. 71,01

v/100

Kr. 61,55

Denne kombination eksistere ikke.

Køb

Technical Specifications

• Low power operation (2,7...5,5V resp. 3,0...5,5V)
• High common mode transient immunity: >25kV/μs
• High temperature operation: -40...+105°C


ADUM_	Approvals	U_ISO	Channels	Data Rate	I_DD5	I_DD3
		[V AC]		[MBd]	[mA]	[mA]
1250ARZ	¹⁾²⁾³⁾	2500	2	DC...1	5,0	3,0
1251ARZ	¹⁾²⁾³⁾	2500	2	DC...1	6,0	3,0
1300ARWZ	^1)2)3)4)	2500	3	DC...1	2,5	1,7
1400ARWZ	^1)2)3)4)	2500	4	DC...1	2,8	1,9
1400CRWZ	^1)2)3)4)	2500	4	DC...90	100	65
1402ARWZ	^1)2)3)4)	2500	4	DC...1	2,1	1,5
1402CRWZ	^1)2)3)4)	2500	4	DC...90	62	39
2400ARWZ	¹⁾²⁾³⁾	5000	4	DC...1	2,8	1,9
2400CRWZ	¹⁾²⁾³⁾	5000	4	DC...90	100	65
2401ARWZ	¹⁾²⁾³⁾	5000	4	DC...1	2,4	1,6
2401CRWZ	¹⁾²⁾³⁾	5000	4	DC...90	82	52
2402ARWZ	¹⁾²⁾³⁾	5000	4	DC...1	2,1	1,5
2402CRWZ	¹⁾²⁾³⁾	5000	4	DC...90	62	39
U_ISO = Isolation Voltage, I_DD5 = Max. Supply Current Per Channel At U_S = 5V, I_DD3 = Max. Supply Current Per Channel At U_S = 3V (ADUM125_ At 3,3V), U_S = Supply Voltage, ¹⁾UL, ²⁾ VDE, ³⁾CSA, ⁴⁾TÜV

Manufacturer

Analog Devices
http://www.analog.com
