Optoc. 3,75kV 80V 50mA >130% MFP4
Varenummer:
107-860
Varekode:
PC357N2TJ00F
Vægt:
0 g
Lagerstatus:
Ikke på lager
Gruppe:
X7245
SHARP DC Optocouplers
Transistor Output
Series: PC_
Case: DIP/DIL, MFP
SHARP DC Optocouplers
Transistor Output
Series: PC_
Case: DIP/DIL, MFP
| Technical Specifications |
| Part Nr. | Approvals | UISO | CTR | @IF | UCEO |
| [V AC] | [%] | [mA] | [V] | ||
| PC123X2YFZ0F | 1)3)4)5)6)7)8)9) | 5000 | 100...250 | 5 | 70 |
| PC3H7J00000F | 1) | 2500 | 20...400 | 1 | 80 |
| PC357N14J00F | 1) | 3750 | - | - | 80 |
| PC357N2TJ00F | 1) | 3750 | 130...260 | 5 | 80 |
| PC357NTJ000F | 1) | 3750 | 50...600 | 5 | 80 |
| PC817XJ0000F | 1) | 5000 | 50...600 | 5 | 80 |
| UISO = Isolation Voltage, CTR = Current Transfer Ratio, IF = Forward Current, UCEO = Collector Emitter Voltage At Open Base, 1) UL, 2) TÜV, 3) VDE, 4) CSA, 5) BS/EI, 6) DEMKO, 7) FIMKO, 8) NEMKO, 9)SEMKO | |||||
 | |||||
| Terms of Delivery |
| Minimum order quantity: please see price list column "MOQ". |
|
| Manufacturer |
 |
| http://www.sharpsma.com |
|
