SMD TSPD bip 80A 160V SMB

Varenummer:

107-351

Varekode:

TB1800M

Vægt:

0 g

Lagerstatus:

Ikke på lager

v/50

Kr. 7,31

v/3000

Kr. 2,38

Denne kombination eksistere ikke.

Technical Specifications

• Bidirectional protection in a single device
• The plastic conforms to UL94V-0


Part Nr.	I_R	@U_RM	U_BOmax	I_BO-	I_BO+	I_pp
	[μA]	[V]	[V]	[mA]	[mA]	[A]
TB0640M	5	58	77	50	800	80
TB0900M	5	75	98	50	800	80
TB1100M	5	90	130	50	800	80
TB1300M	5	120	160	50	800	80
TB1800M	5	160	220	50	800	80
TB2600M	5	220	300	50	800	80
TB4000M	5	360	450	50	800	80
I_R = Max. Reverse Current, U_RM = Stand-Off Voltage, U_BOmax = Max. Breakover Voltage, I_BO- = Min. Breakover Current, I_BO+ = Max. Breakover Current, I_pp = Reverse Peak Pulse Current

Manufacturer

http://www.liteon-semi.com

Stregkode: 107351
Intern reference: 107351
Varekode: TB1800M
