Thyr/Thyr 340A 1600V C32
Varenummer:
107-325
Varekode:
MCC200-16IO1
Vægt:
160 g
Lagerstatus:
Ikke på lager
Gruppe:
V8435
IXYS Thyristor-/Diode-Modules up to 400A
Series: MCC_, MCD_, MDD_
Case: TO240AA, C32, Y1-CU
IXYS Thyristor-/Diode-Modules up to 400A
Series: MCC_, MCD_, MDD_
Case: TO240AA, C32, Y1-CU
| Technical Specifications |
| Part Nr. | URRM | IT(RMS) | IT(AV) | @TC | rT |
| [V] | [A] | [A] | [°C] | [mW] | |
| MCC26-12IO1B | 1200 | 50 | 27 | 85 | 11,0 |
| MCC26-16IO8B | 1600 | 50 | 27 | 85 | 11,0 |
| MCC44-12IO1B | 1200 | 80 | 49 | 85 | 5,3 |
| MCC44-16IO1B | 1600 | 80 | 49 | 85 | 5,3 |
| MCC44-18IO8B | 1800 | 80 | 49 | 85 | 5,3 |
| MCC56-12IO8B | 1200 | 100 | 60 | 85 | 3,7 |
| MCC56-16IO8B | 1600 | 100 | 60 | 85 | 3,7 |
| MCC56-18IO1B | 1800 | 100 | 60 | 85 | 3,7 |
| MCC72-12IO1B | 1200 | 180 | 85 | 85 | 3,2 |
| MCC72-16IO8B | 1600 | 180 | 85 | 85 | 3,2 |
| MCC95-08IO1B | 800 | 180 | 116 | 85 | 2,4 |
| MCC95-16IO1B | 1600 | 180 | 116 | 85 | 2,4 |
| MCC162-08IO1 | 800 | 300 | 181 | 85 | 1,15 |
| MCC200-16IO1 | 1600 | 340 | 216 | 85 | 1,0 |
| MCC224-22IO1 | 2200 | 400 | 240 | 85 | 0,76 |
| MCD26-08IO8B | 800 | 50 | 27 | 85 | 11,0 |
| MCD26-12IO1B | 1200 | 50 | 27 | 85 | 11,0 |
| MCD56-08IO8B | 800 | 100 | 60 | 85 | 3,7 |
| MCD200-16IO1 | 1600 | 340 | 216 | 85 | 1,0 |
| URRM = Max. Peak Recurrent Reverse Voltage, IT(RMS) = Max. RMS Forward Current, IT(AV) = Max. Average Forward Current, TC = Case Temperature, rT = Slope Resistance | |||||
 | |||||
| Technical Specifications |
| Part Nr. | URRM | IT(RMS) | IF(AV) | @TC | rT |
| [V] | [A] | [A] | [°C] | [mW] | |
| MDD26-16N1B | 1600 | 60 | 36 | 100 | 6,1 |
| MDD44-16N1B | 1600 | 100 | 59 | 100 | 4,3 |
| MDD56-16N1B | 1600 | 150 | 71 | 100 | 3,0 |
| MDD95-16N1B | 1600 | 180 | 120 | 105 | 1,95 |
| MDD95-22N1B | 2200 | 180 | 120 | 105 | 1,95 |
| URRM = Max. Peak Recurrent Reverse Voltage, IF(RMS) = Max. RMS Forward Current, IT(AV) = Max. Average Forward Current, TC = Case Temperature, rT = Slope Resistance | |||||
| |||||
| Note |
| Screws are not included in delivery, you will find suitable screws starting at product group G8111. |
|
| Additional Products |
| We will also deliver on request all other articles from IXYS, forward orders possible. |
|
| Terms of Delivery |
| Minimum order quantity: please see price list column "MOQ". Articles in bold print in stock, other articles available on request. |
|
| Manufacturer |
 |
| http://www.ixys.com |
|
