PCB Edge Card Connector 3,5 2-Pole Green
Varenummer:
104-487
Varekode:
AK4350/03
Vægt:
0 g
Lagerstatus:
Ikke på lager
Gruppe:
F9583
PTR Edge Card Connectors
Series: AK4350
Without Guiding Slot
Pitch: 3,5mm
PTR Edge Card Connectors
Series: AK4350
Without Guiding Slot
Pitch: 3,5mm
| Features |
| • Double-sided edge card connector • Without guiding slot on the PCB • For tin-plated sliding contact on the PCB as contact resistance • Current-carrying capacity of up to 6A per contact • Low height of 10,3mm • Connection for up to three single wire conductors (max.0,5mm2) per contact |
 |
| Technical Specifications |
| |
| Rated Voltage (EN 61984): | 160V |
| Rated Current (T60): | 6A |
| Test Voltage: | 2,5kV |
| Rated Cross Section | |
| Single Wire: | 0,5mm2 |
| Stripped Length: | 8,5mm |
| Clamp: | Stainless Steel |
| Contact Spring: | Cu |
| Insulating Material: | PA |
| Temperature Range: | -30°C...+105°C |
| Flammability Class: | UL94V-0 |
| Colour: | Green |
| |
| Dimensions |
| Part Nr. | L | H | D |
| [mm] | |||
| AK4350/03 | 10,5 | 10,3 | 19 |
| |||
| Approvals |
  |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces |
|
| Manufacturer |
 |
| http://www.ptr-messtechnik.de |
|
Stregkode:
104487
Intern reference:
104487
Varekode:
AK4350/03
