PCB Edge Card Connector 3,5 2-Pole Green

Varenummer:
104-486
Varekode:
AK4350/02
Vægt:
0 g
Lagerstatus:
Ikke på lager

kr 0,00 0.0 DKK kr 0,00 Inklusiv moms

kr 0,00 Inklusiv moms

Anmod os om en pris

v/10
Kr. 6,75
v/25
Kr. 5,62
v/100
Kr. 4,50
v/1000
Kr. 3,38

Denne kombination eksistere ikke.

https://elektroniklavpris.odoo.com/web/image/product.template/60237/image_1920?unique=84270ad https://elektroniklavpris.odoo.com/web/image/product.template/60237/image_1920?unique=84270ad
Features
• Double-sided edge card connector
• Without guiding slot on the PCB
• For tin-plated sliding contact on the PCB as contact resistance
• Current-carrying capacity of up to 6A per contact
• Low height of 10,3mm
• Connection for up to three single wire conductors (max.0,5mm2) per contact
Technical Specifications
Rated Voltage (EN 61984):
 160V
Rated Current (T60):
 6A
Test Voltage:
 2,5kV
Rated Cross Section
Single Wire:
 0,5mm2
Stripped Length:
 8,5mm
Clamp:
 Stainless Steel
Contact Spring:
 Cu
Insulating Material:
 PA
Temperature Range:
 -30°C...+105°C
Flammability Class:
 UL94V-0
Colour:
 Green
Dimensions
Part Nr.
 L
 H
 D
    [mm]

AK4350/02 7,00
 10,3
 19
AK4350/03 10,5
 10,3
 19
AK4350/04 14,0
 10,3
 19
AK4350/05 17,5
 10,3
 19
AK4350/06 21,0
 10,3
 19
Approvals

Manufacturer

http://www.ptr-messtechnik.de
Kontakt os

Stregkode: 104486
Intern reference: 104486
Varekode: AK4350/02
