IEC C14 Plug KM Fuse Line Switch EMC
Varenummer:
104-377
Varekode:
KM01.1105.11
Vægt:
40 g
Lagerstatus:
Ikke på lager
Gruppe:
F5569
SCHURTER IEC Male Power Insert Connectors
Series: KM
With Rocker Switch and Fuseholder
Pin Temperature: 70°C
F5569
SCHURTER IEC Male Power Insert Connectors
Series: KM
With Rocker Switch and Fuseholder
Pin Temperature: 70°C
| Features |
| • Combination consists of: - IEC inlet connector - 2-pole black and non-illuminated rocker switch - 2-pole fuse holder for two fuses (5x20mm), Fuse drawer FT4301-1401 must be ordered separately (see note) • Connection by 4,8x0,8mm quick-connect terminal • Without or with shield optionally • Snap-in assembly |
 |
| Technical Specifications |
| |
| Nr. of Poles: | 2 + PE |
| Continuous Current: | 10A |
| Fuse Holder: | 6,3A |
| Rated Voltage: | 250V AC |
| Pin Temperature: | 70°C |
| Temperate Range: | -25°C to +85°C |
| |
| Selection Table |
| Part Nr. | EMC | Imprint | Assembly | Front Plate |
| KM_ | Shield | Thickness | ||
| [mm] | ||||
| 00-1105-11 | no | I/O | Snap-in | 1/1,5/2/2,5 |
| 01-1105-11 | yes | I/O | Snap-in | 1/1,5/2/2,5 |
| ||||
| Note |
| • Fuse drawer FT4301-1401 must be ordered seperately, see product group F5563. |
|
| Approvals |
  10 |
|
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 1 piece |
|
| Manufacturer |
 |
| http://www.schurter.de |
|
Stregkode:
498-2647
Intern reference:
104377
Varekode:
KM01.1105.11
