Female Header 1R Straight 1x5-Pole Au
Varenummer:
104-197
Varekode:
MBL105G
Vægt:
0 g
Lagerstatus:
Lager: 2 stk.
Gruppe:
F2711
MPE GARRY Female Headers
Series: BL12
Single Row, Straight
Height: 4,3mm
Pitch: 2,00mm
MPE GARRY Female Headers
Series: BL12
Single Row, Straight
Height: 4,3mm
Pitch: 2,00mm
| Features |
| • Flash gold design • Black insulation shell • Suitable for square pins 0,5x0,5mm |
 |
| Technical Specifications |
| |
| Insulation Shell: | Thermoplastic, UL94V-0 |
| Contact Material: | Phosphor-Bronze |
| Contact Surface: | Gold-plated |
| Rated Current: | 1,5A |
| Rated Voltage: | 150VRMS/150V DC |
| Dielectric Strength (1Min.): | 500VRMS |
| Temperature Range: | -40...+105°C |
| Solderability (10s): | 260°C |
| |
| Terms of Delivery |
| Minimum order quantity: 1 PKU = 10 pieces |
|
| Manufacturer |
 |
| http://www.mpegarry.de |
|
Stregkode:
104197
Intern reference:
104197
Varekode:
MBL105G
